VIVOTEK
92 - User's Manual
Group: uart
NAME VALUE SECURITY
(get/set)
DESCRIPTION
ptzdrivers_i<0~19, 127>_name string[40] 1/4 Name of the PTZ driver.
ptzdrivers_i<0~19, 127>_location string[128] 1/4 Full path of the PTZ driver.
Group: uart_i<0~(n-1)> n is uart port count
NAME VALUE SECURITY
(get/set)
DESCRIPTION
baudrate 110,300,600,120
0,2400,3600,480
0,7200,9600,192
00,38400,57600,
115200
4/4 Set baud rate of COM port.
databit 5,6,7,8 4/4 Data bits in a character frame.
paritybit none,
odd,
even
4/4 For error checking.
stopbit 1,2 4/4 1
2-1.5 , data bit is 5
2-2
uartmode rs485,
rs232
4/4 RS485 or RS232.
uartreset 4/4 Set this flag to true to apply change in UART
configuration.
customdrvcmd_i<0~9> string[128] 1/4 PTZ command for custom camera.
speedlink_i<0~4>_name string[40] 1/4 Additional PTZ command name.
speedlink_i<0~4>_cmd string[128] 1/4 Additional PTZ command list.
ptzdriver 0~19,
127 (custom),
128 (no driver)
4/4 The PTZ driver is used by this COM port.
Group: privacymask_c<0~(n-1)> for n channel product
NAME VALUE SECURITY
(get/set)
DESCRIPTION
enable 4/4 Enable privacy mask.
win_i<0~4>_enable 4/4 Enable privacy mask window.
win_i<0~4>_name string[14] 4/4 Name of the privacy mask window.
win_i<0~4>_left 0 ~ 320/352 4/4 Left coordinate of window position.
