Top view—On-screen Display (OSD) buttons and LEDs
I
TEM
L
ABEL
D
ESCRIPTION
S
EE
PAGE
:
1.
(Power button)
Turns the projector On or Off.
2.
BLANK
Displays a blank screen and mutes audio
3.
◄ (Left cursor) /
Volume
Navigates and changes settings in the OSD
Quick Menu – For Volume
4.
MODE / Enter
Enter or confirm highlighted OSD menu item
5.
MENU
Opens and exits OSD menus
6.
▲ (Up cursor) /
Keystone+
Navigates and changes settings in the OSD
Quick Menu – For Keystone
7.
AUTO
Optimizes image size, position, and resolution
8.
► (Right cursor) /
Volume
Navigates and changes settings in the OSD
Quick Menu – For Volume
9.
SOURCE
Enter the Source menu
10.
▼ (Down cursor) /
Keystone-
Navigates and changes settings in the OSD
Quick Menu – For Keystone
Red
Lamp is ready to be powered-on.
11.
READY LED
Flashing
Lamp not ready (Warm-up/shutting down/cooling)
(see LED Error Messages on page 46)
12.
TEMP LED
Flashing
Error code
– 3 –
