Projection Distance vs. Projection Size
D935VX / D940VX / D930TX Projection Distance and Size Table
D935VX
T
ELE
W
IDE
Distance
(m)
1.34 3.58 4.47 8.94 1.54 3.09 3.86 11.58
Diagonal
(inches) 30 80 100 200 40 80 100 300
Keystone
(degree) 12.3 12.3 12.3 12.3 14.2 14.2 14.2 14.2
Image Height (mm)
457.2
1219.2
1524
3048
609.6
1219.2
1524
4572
Image Width (mm)
609.6
1625.6
2032
4064
812.8
1625.6
2032
6096
A
(mm)
64 170.7 213.4 426.7 85.3 170.7 213.4 640.1
D940VX
T
ELE
W
IDE
Distance
(m)
1.28 3.41 4.27 8.53 1.46 2.93 3.66 10.97
Diagonal
(inches) 30 80 100 200 40 80 100 300
Keystone
(degree) 12.55 12.55 12.55 12.55 14.56 14.56 14.56 14.56
Image Height (mm)
457.2
1219.2
1524
3048
609.6
1219.2
1524
4572
Image Width (mm)
609.6
1625.6
2032
4064
812.8
1625.6
2032
6096
A
(mm)
56.4 150.5 188.1 376.3 75.3 150.5 188.1 564.4
D930TX
T
ELE
Distance (m)
0.53
1.05
1.32
3.95
Diagonal (inches)
40
80
100
300
Keystone (degree)
34.9
34.9
34.9
34.9
Image Height (mm)
609.6
1219.2
1524
4572
Image Width (mm)
812.8
1625.6
2032
6096
A (mm)
62.8
125.6
157
470.9
