Rear view
I
TEM
L
ABEL
D
ESCRIPTION
S
EE PAGE
:
1.
AC IN
Connect the POWER CABLE
2.
(USB)
Connect the USB CABLE from a computer
3.
VGA OUT
Connect the RGB CABLE to a display
4.
LAN
Connect a LAN CABLE from a computer
5.
VGA IN – 1
Connect the RGB CABLE from a computer and
components
6.
VGA IN – 2
Connect the RGB CABLE from a computer and
components
7.
HDMI
Connect an HDMI CABLE from an HDMI device
8.
S-VIDEO IN
Connect the S-VIDEO CABLE from a video device
9.
VIDEO IN
Connect the COMPOSITE CABLE from a video device
10.
Speaker
Outputs audio sound
11.
Kensington Lock
Secure to permanent object with a Kensington® Lock
system
12.
AUDIO IN (L and R)
Connect the COMPOSITE CABLES from a video de-
vice
13.
RS-232
Connect RS-232 serial port cable for remote control
14.
AUDIO IN
AUDIO OUT
Connect an AUDIO CABLE from the input device
Connect an AUDIO CABLE for audio loop through
Note:
If your video equipment has various input sources, it is recommended to connect in priority of
HDMI/DVI, component (thru VGA), S-Video, Composite for better picture quality.
