P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
VENTILATION
Professional Built-In 18”H.
Wall Hood/Chimney Wall Hood
Recommended Ventilator Kits
• See Installation Requirements table for recommendations for each hood model
• One ventilator, one duct run for any size hood/ventilator
• Variable speed controls for custom venting—separate on/off switch allows you to leave ventilator at favorite/most-used
setting
• Choose from interior- or exterior-power ventilator kits
• Must use Viking ventilator kits with Viking hoods; use of non-Viking kits voids product warranty
Duct Covers
• Specify finish code following accessory model number (for example, DCW24-SS)
o Professional models
• For VWH hoods
• 12”D.
• Extends height of hood by 12”—conceals duct
• Available in Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG),
Taupe (TP), Biscuit (BT), Cotton White (CW), Oyster Gray (OG), Golden Mist (GM), Lemonade (LE), Sage (SA), Mint
Julep (MJ), Sea Glass (SE), Iridescent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Red (RR), Apple Red (AR),
Burgundy (BU), Plum (PL), Chocolate (CH), and Cobalt Blue (CB).
Duct Cover Extensions
• For use with Professional chimney wall hoods (VCWH)
• Extends height of hood by up to 12” (for 10’ ceilings)
• Replaces adjustable duct cover supplied with hood
• Specify finish code following accessory model number (for example, DCCE1210-SS)
o Available in Stainless Steel (SS), Black (BK), White (WH), Metallic Silver (MS), Graphite Gray (GG), Stone Gray (SG),
Taupe (TP), Biscuit (BT), Cotton White (CW), Oyster Gray (OG), Golden Mist (GM), Lemonade (LE), Sage (SA), Mint
Julep (MJ), Sea Glass (SE), Iridescent Blue (IB), Viking Blue (VB), Pumpkin (PM), Racing Red (RR), Apple Red (AR),
Burgundy (BU), Plum (PL), Chocolate (CH), and Cobalt Blue (CB).
✪ Installation Notes & Accessories
Kit model Description Hood models Approx. ship wt. lbs. (kg)
VINV300 300 CFM interior-power VWH/VCWH24481/30481/36481/36781 27 (12.2)
VINV600 600 CFM interior-power VWH/VCWH24481/30481/36481/36781/42481 27 (12.2)
VINV1200 1,200 CFM interior-power VWH/VCWH36481/36781/42481/48481/ 43 (19.4)
48781/54481/60481/60781/66481
DEV900 900 CFM exterior-power VWH/VCWH24481/30481/36481/36781/42481 39 (17.6)
DEV1200 1,200 CFM exterior-power VWH/VCWH24481/30481/36481/36781/42481/ 53 (23.9)
48481/48781/54481/60481/60781/66481
DEV1500 1,500 CFM exterior-power VWH/VCWH48481/48781/54481/60481/60781/66481 47 (21.3)
DIL900 900 CFM in-line power VWH/VCWH24481/30481/36481/36781/42481 20 (9.1)
DIL1200 1,200 CFM in-line power VWH/VCWH24481/30481/36481/36781/42481/48481/ 25 (11.3)
48781/54481/60481/60781/66481
Model Description Approx. ship wt. lbs. (kg)
DCW24 Professional 24”W. duct cover 9 (4.0)
DCW30 Professional 30”W. duct cover 10 (4.5)
DCW36 Professional 36”W. duct cover 11 (5.0)
DCW42 Professional 42”W. duct cover 13 (5.9)
DCW48 Professional 48”W. duct cover 14 (6.3)
DCW54 Professional 54”W. duct cover 23 (10.4)
DCW60 Professional 60”W. duct cover 24 (10.8)
DCW66 Professional 66”W. duct cover 26 (11.7)
Model Description Approx. ship wt. lbs. (kg)
DCCE1210 Duct cover extension (for 30”W., 36”W., & 42”W. hoods) 6 (2.7)
DCCE1810 Duct cover extension (for 48”W. & 54”W. hoods) 8 (3.6)
DCCE2410 Duct cover extension (for 60”W. & 66”W. hoods) 11 (4.9)
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
