2175BEVS/2175BEVOL2 Beverage Center
www.U-LineService.com 2 03/2008
Contents
1-Follow Safety Precautions . . . . . . . . . . . . . . . . . . . . . 2
2-Inspect and Plan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Exterior Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3-Prepare Site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Cut-Out Dimensions . . . . . . . . . . . . . . . . . . . . . . . . 4
Product Dimensions . . . . . . . . . . . . . . . . . . . . . . . . 5
Door Swing/Clearances Information . . . . . . . . . . . 5
Other Site Requirements . . . . . . . . . . . . . . . . . . . . 5
Side-By-Side Installation Instructions . . . . . . . . . . 6
4-Prepare Racks and Door Frame . . . . . . . . . . . . . . . . . 6
Wine Rack Removal/Installation . . . . . . . . . . . . . . 6
Wood Trim Finishing . . . . . . . . . . . . . . . . . . . . . . . 7
Reversing the Door . . . . . . . . . . . . . . . . . . . . . . . . . 8
Overlay Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Frame Preparation . . . . . . . . . . . . . . . . . . . . . . . . . 10
Prepare the New Overlay Panel . . . . . . . . . . . . . . . 11
Attaching the Overlay Panel . . . . . . . . . . . . . . . . . 11
Assembling Door to Cabinet . . . . . . . . . . . . . . . . . 12
5-Adjust Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Checking Door Alignment . . . . . . . . . . . . . . . . . . . 13
Adjusting Door Alignment . . . . . . . . . . . . . . . . . . 13
6-Prepare Power Supply . . . . . . . . . . . . . . . . . . . . . . . . 14
Electrical Specifications . . . . . . . . . . . . . . . . . . . . . 14
7-Level the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Leveling Information . . . . . . . . . . . . . . . . . . . . . . . 14
Installation Tip . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8-Install the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Anti-tip Bracket Installation . . . . . . . . . . . . . . . . . 14
Single Unit Installation . . . . . . . . . . . . . . . . . . . . . . 15
Side-by-Side Installation . . . . . . . . . . . . . . . . . . . . . 16
Installation Troubleshooting . . . . . . . . . . . . . . . . . 16
9-Start-Up for the First Time . . . . . . . . . . . . . . . . . . . . . 16
Initial Start-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Start-Up Troubleshooting . . . . . . . . . . . . . . . . . . . 16
Who to Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Service Information . . . . . . . . . . . . . . . . . . . . . . . . 16
IMPORTANT
PLEASE READ all instructions completely before
attempting to install or operate the unit.
• This unit requires connection to a grounded (three-
prong), polarized receptacle that has been placed by a
qualified electrician in accordance with applicable
electrical codes.
Safety Alert Definitions
Safety items throughout this guide are labeled with a
Danger, Warning or Caution based on the risk type:
DANGER
Danger means that failure to follow this safety
statement will result in severe personal injury or
death.
WARNING
Warning means that failure to follow this safety
statement could result in serious personal injury,
or death.
CAUTION
Caution means that failure to follow this safety statement
may result in minor or moderate personal injury, property
or equipment damage.
1 Follow Safety Precautions
