7
Parts of the Phone
The following illustrations show you all of the different parts of your phone.
Handset
1
2
3
5
6
7
8
9
10
11
12
15
19
20
21
16
18
17
13
4
14
22
Headset jack cover 1.
Belt clip hole 2.
Speakerphone speaker and ringer 3.
Handset battery compartment 4.
new message 5. LED
Handset earpiece 6.
LCD display 7.
[Clear/Int’com] 8. key
[ 9. ] key (up)
[ 10. /Flash] key (talk/fl ash)
[ 11. ] key (phonebook/left)
[ 12. * /tone] key
[Redial/Pause] 13. key
[Menu/Select] 14. key
[ 15. /Mute] key (messages/mute)
[ 16. ] key (caller ID/right)
[ 17. ] key (end call)
[ 18. ] key (down)
[#] 19. key
[ 20. ] key (speaker)
Handset microphone 21.
Handset charging contacts 22.
