Model Designation
Air Inlets
(Inches/ Millimeters)
Natural Gas
Orifice
Liquid Petroleum
Orifice
Input
KW
BTU/HR
Model Tube
Configuration
Tube Dia.
(In)
Burner Intake
(in. / M.M.)
Fan Inlet
(in. / M.M.)
Injector
Diameter
(inches )
Manifold
Pressure
(in.W.C.)
Injector
Diameter
(inches)
Manifold
Pressure
(in./mm)
S-20
3"
1.125"/29mm
1.312"/33mm
0.130"
1.9
0.080"
6.7
S-25
3"
1.125"/29mm
1.438" /37mm
0.130"
1.9
0.080"
6.7
S-30
3"
1.125"/29mm
1.438" /37mm
0.130"
1.9
0.080"
6.7
U-20
3"
1.125"/29mm
1.187/30mm
0.130"
1.9
0.080"
6.7
GH/ER/AL/SC
12/40,000
U-30
3"
1.125"/29mm
1.187/30mm
0.130"
1.9
0.080"
6.7
S-20
3"
1.312"/33MM
1.438"/37 MM
0.130"
3
0.080"
6.7
S-25
3"
1.125"/29 MM
1.438"/37 MM
0.130"
3
0.080"
6.7
S-30
3"
1.125"/29 MM
1.438"/37 MM
0.130"
3
0.080"
6.7
U-20
3"
1.312"/33MM
1.438"/37 MM
0.130"
3
0.080"
6.7
GH/ER/AL/SC
15/150000
U-30
3"
1.312"/33MM
1.312"/33 MM
0.130"
3
0.080"
6.7
S-20
3"
1.750"/44 MM
2.00"/50 MM
0.161"
2.4
0.098"
6.7
S-25
3"
1.312"/33 MM
1.438"/37 MM
0.161"
2.4
0.098"
6.7
S-30
3"
1.312"/ 33 MM
1.438"/37 MM
0.161"
2.4
0.098"
6.7
S-40
3"
1.312" /33 MM
1.438"/37 MM
0.161"
2.4
0.098"
6.7
S-20
3"
1.312" /33 MM
1.750"/44MM
0.161"
2.4
0.098"
6.7
S-30
3"
1.312" /33 MM
1.438"/37 MM
0.161"
2.4
0.098"
6.7
GH/ER/AL/SC
18/60,000
S-40
3"
1.312" /33 MM
1.312"/33MM
0.161"
2.4
0.098"
6.7
S-20
3"
1.750"/44 MM
2.625"/67 MM
0.161"
3.8
0.098"
10.5
S-25
3"
1.750"/44 MM
2.00"/50 MM
0.161"
3.8
0.098"
10.5
S-30
3"
1.750"/44 MM
2.00/50 MM
0.161"
3.8
0.098"
10.5
S-40
3"
1.750"/44 MM
1.75"/44MM
0.161"
3.8
0.098"
10.5
U-20
3"
1.750"/44 MM
2.625"/67 MM
0.161"
3.8
0.098"
10.5
GH/ER/AL/SC
22/75,000
U-30
3"
1.750"/44 MM
2.00/50 MM
0.161"
3.8
0.098"
10.5
U-40
3"
1.750"/44 MM
2.00/50 MM
0.161"
3.8
0.098"
10.5
S-40
4"
2.312"/59 MM
2.00"/50 MM
0.182"
4.9
1.20"
10
S-50
4"
2.312"/59 MM
2.00"/50 MM
0.182"
4.9
1.20"
10
S-60
4"
2.312"/59 MM
2.00"/50 MM
0.182"
4.9
1.20"
10
GH/ER/l/SC
29/100,000
U-35
4"
2.312"/59 MM
2.00"/50 MM
0.182"
4.9
1.20"
10
S-40
4"
2.312"/59 MM
2.625"/67MM
0.206"
4.9
0.136"
10
S-50
4"
2.312"/59 MM
2.625"/67MM
0.206"
4.9
0.136"
10
S-60
4"
2.312"/59 MM
2.625"/67MM
0.206"
4.9
0.136"
10
GH/ER/AL/SC
38/130,000
U-35
4"
2.312"/59 MM
2.625"/67MM
0.206"
4.9
0.136"
10
S-40
4"
2.312"/59 MM
4.00"/100MM
0.228"
4.6
0.149"
10
S-50
4"
2.312"/59 MM
4.00"/100MM
0.228
4.6
0.149"
10
S-60
4"
2.312"/59 MM
4.00"/100MM
0.228
4.6
0.149"
10
SC/ER/GX
44/150,000
U-35
4"
2.312"/59 MM
4.00"/100MM
0.228
4.6
0.149"
10
