1115R, 1175R, 29R, 1175BEV
To defrost:
1. Turn unit off.
2. Remove all products from the interior and prop the
door in an open position (2 in. (5 cm) minimum).
3. Allow the frost to completely melt naturally. Clean the
interior and all removed components using a mild non-
abrasive detergent and warm water solution applied
with a soft sponge or non-abrasive cloth. NOTE: DO
NOT use any solvent-based or abrasive cleaners. They
will discolor or damage the interior.
4. Dampen a soft sponge or non-abrasive cloth in clean
water and wipe down the cabinet interior and removed
components to remove any detergent residue. Rinse the
sponge or cloth in clean water and repeat as necessary
until the cabinet and components are clean.
5. When the interior is dry, turn unit on.
Condenser Cleaning
Interval - Every Three Months
To maintain operational efficiency, keep the front grille
free of dust and lint, and clean the condenser every three
months. Depending on environmental conditions, more
or less frequent cleaning may be necessary.
WARNING
Disconnect electric power to the unit before
cleaning the condenser.
WARNING
DO NOT touch the condenser fins. The condenser
fins are SHARP and can be easily damaged.
IMPORTANT
IMPORTANT
DO NOT use any type of cleaner on the condenser
unit.
Model 29R
1. Disconnect power to the unit.
Figure 11
2. Remove the control knob (Figure 11, 1) by pulling it
straight out, away from grille.
3. Remove two screws from grille (Figure 11, 2) and save.
4. Remove grille and grille cap from unit.
Figure 12
5. Clean the condenser coil (Figure 12, 1) using a using a
soft brush with a “combing” action or vacuum cleaner.
Do not touch the condenser coil.
Figure 13
6. Make sure grille cap is behind grille in slots provided in
grille (Figure 13, 1) before attaching grille to unit, and
secure but do not overtighten both grille screws
(Figure 13, 2).
7. Reinstall the control knob (Figure 11, 1).
8. Reconnect power to the unit.
Model 1115R
1. Disconnect power to the unit.
Figure 14
2. Loosen the two screws (Figure 14, 1) completely.
NOTE: Screws are held in the grille by o-ring retainers,
and will not come free of the grille.
3. Remove grille (Figure 14, 2) and grille cap (Figure
14, 3) from unit.
2
1
ULIN_0197_A
1
ULIN_0153_A
ULIN_0198_A
2
1
2
3
1
ULIN_0155_A
