5
Controls.and.Functions
XS1455+1.Handset.
. Handset antenna
2. Handset battery compartment
3. Handset earpiece
4. LCD display
5. [vol/ / / ]
(volume & ringer up/down) key
6. [cid/menu] key
7. [ /tone/ ] (left cursor) key
8. [redial/pause] key
9. [select/channel] key
(XS455+)
[select/remote] key (XS455)
0. [memory] key
. [end] key
2. [talk/flash] key
3. [#/ ] (right cursor) key
4. [delete/transfer] key
(XS455+)
[delete/channel] key
(XS455)
5. Handset ringer speaker
6. Handset microphone
7. Handset charging contacts
