Mounting.the.Base.Unit.on.a.Wall
Standard.wall.plate.mounting
This phone can be mounted on any standard wall plate.
) Snap the wall mount adapter into the notches on the base top.
2) Plug the AC adapter into the DC.IN.9V jack.
3) Plug the AC adapter into a standard 240V AC wall outlet.
4) Plug the telephone cord into the TEL.LINE jack.
5) Route the telephone cord through the groove as shown.
6) Plug the telephone cord into the telephone outlet.
7) Align the mounting slots on the base with the mounting posts on the wall.
Then push in and down until the phone is firmly seated.
1
6
7
7
3
2 4
5
