all Mounting the Base

Wall plate

(To AC outlet)

Place the mounting slots over the

pins on the wall plate.

Slide the base

down to lock it

into place.

On the base unit, pull the handset

retainer out of the slot.

Rotate it clockwise 180 degrees and

flip the retainer from front to back.

Slide it back into the slot.

The retainer holds the corded

handset in place.

Notes:.Mounting.the.phone.directly.on.the.wall

•. Be.sure.the.wall.is.capable.of.supporting.the.weight.

of.the.phone,.and.use.the.proper.type.of.anchoring.

device.for.the.wall.material.

•. Insert.two.#10.screws.(minimum.length.of.1.

inches,.not.supplied).into.the.wall,.3.

.inches.

apart..

•. Leave.the.screw.heads.

.inch.away.from.the.wall.to.

allow.room.for.mounting.the.phone..

•. Align.the.mounting.slots.over.the.screws.and.slide.

the.base.down.into.place.as.shown.above.
