Overview
5
Overview
Overview
4
DC 5VDC 5V
Personal Multimedia Player
Designed for plawa '2004
1 LCD display
2 Charge indication lamp: This lights on when the battery is charged by the input of DC power or
connecting a USB cable.
3 REC button: Use to record an external input signal. Use to display operating time while video play-
back and recording.
4 REPEAT button: Use to repeat playback.
5 MENU button: Use to return to the menu screen.
6 VOL -,+ buttons: Use to adjust the volume.
SLIDE TIME buttons: Use to select a showing time of the slide show.
7 (Power/Stop) button: Use to turn on or off the power of the main set, or use to stop play-
back.
8 (JOG/Select/Play/Pause/Search/Skip) button
JOG ( ): Move it left or right to go to, search, or skip the desired position in the menu.
SELECT ( ): Use to select a menu, or play/pause the player.
9 AV IN (external input) jack: Use to connect an external component.
10 DC IN (DC power input) jack: Use to input power.
11 SD CARD insertion slot
12 Charger insertion slot
13 USB Connection jack
14 NTSC/PAL switch: Use to select a display format on LCD display.
15 HOLD switch: If the HOLD function is set, the player does not operate even in the entry of another
button during playback.
16 LCD ON/OFF switch: Use to turn on or off the LCD display.
17 Headphone jack: Use to connect a headphone.
18 55° TILT: Install hand strap circular stand into 55° slot.
19 30° TILT: Install hand strap circular stand into 30° slot.
