UNIDEN Model uh095sx Dual Band (UHF CB/AM CB) Radio
Introduction
The Uniden uh095sx is designed to provide you with years of trouble free service. Its rugged
components and materials are capable of withstanding harsh environments. Please read this
Operating Manual carefully to ensure you gain the optimum performance of the unit
The citizen band radio service is licenced in Australia by ACMA Radio-communications
(Citizen Band Radio Stations) Class Licence and in New Zealand by MED General
User Licence for Citizen Band Radio and operation is subject to conditions contained in
those licenses.
Features
Preventive Maintenance:
The following system checks should be made every six to twelve months:
=
Check the Standing Wave Ratio (SWR).
=
Inspect the tightness of all electrical connections.
=
Inspect the antenna coaxial cable for wear or breaks on the shielding.
=
Inspect the tightness of all screws and other mounting hardware.
Troubleshooting:
Should the unit malfunction or perform poorly, follow these procedures:
If the transceiver is completely inoperative: Check the power cord and fuse.
If there is trouble with receiving: Check the VOLUME control setting. Be sure the SQUELCH is
adjusted properly. Possibly the radio is over-squelched.
If there is trouble with transmitting: Check that the transmission line (coaxial cable) is securely
connected to the ANTENNA connector. Check that the antenna is fully extended for proper
operation. Check that all transmission line (coaxial cable) connections are secure and free of
corrosion.
Blackening may occur on the Liquid Crystal Display if the uh095sx has been
subjected to extreme high temperature (above 60°C) . This is not a fault. Normal LCD
operation resumes when the temperature stabilizes back to standard operating
operating condition (0-55°C).
2
! AM+FM Band 40 Programmable Receive channels (450-
! Voice Activated Function (VOX) 512MHz)
! VOX Mic sensitivity adjustment - 9 levels
! Volume Control with Power On/Off Switch AM Band
! ! LCD Display with Backlight and 3-stage Transmit & Receive AM 40CH (AM Band, TX
Dimmer Power 4W) - See p16 for AUST model/NZ
! Signal Strength Indicator model AM frequencies
! ! RF Power Indicator Variable Squelch with rotary adjust
! One touch AM, FM or AM+FM Band
selectable
FM Band
! ! Dual Watch with Instant Channel Transmit & Receive FM 40CH (UHF-CB, TX
! One touch Instant Channel recalling Power 5W; Transmission is inhibited at CH22
! AM, FM or AM+FM Group Scan with Priority & CH23)
! Channel Watch Duplex Capability (from CH01 - CH08)
! ! AM, FM or AM+FM Open Scan 38 Built-in CTCSS codes and 104 additional
! Busy Channel Lock-out Function DCS codes
! ! Roger Beep Function On/Off Preset FM Squelch with 3 levels
! 5 Different Call Tones
! Memory Backup if power fails
! Scramble
