45
DVS/HVS SPECIFICATIONS
240 480
8 16 32 16 32
Video Format NTSC/PAL
Video Inputs (BNC) 8 16 32 16 32
Video Outputs
DVI-D x 1, SVGA x 1 (Primary Display), RCA x 1 (Spot Monitor)
RCA x4 (480PPS model only)
Looping Outputs (BNC) 8 16 32 16 32
Recording Rate
240 PPS 360×240
120 PPS 720×240
60 PPS 720×480 480 PPS 360×240
240 PPS 720×240
120 PPS 720×480
Live Viewing Rate (PPS) 240 480 480
Audio Recording
(optional 16 channel available)
4
(yes)
16
(yes)
4
(yes)
Sensor / Alarm Inputs 8 16 16 16 16
Alarm Outputs 8 16 16 16 16
PTZ Controls Internal RS-422/485 (over 75 protocols)
Image Compression Proprietary MJPEG
Storage Capacity Up to 4 Terabytes (RAID 5 optional)
LAN 100/1000 Gigabit Ethernet
Critical Recording Archive DVD Multi Burner, Network, USB
Password Control User Defined Access Level
Power Interruption Recovery Automatic restart after power interruption / recording operation resumes
Remote Connection TCP/IP, UDP, Internet, LAN, WAN (Compatible with Microsoft Windows XP, Vista)
Power Input AC 100~240V Input (50 Hz/60Hz)
Central Processing Unit Intel® Dual Core 2 Ghz+ Intel® Core™2 Duo 2 Ghz+
RAM 1 GB
Operating System Microsoft© Windows© XP Embedded
Max PPS Per Channel 30 Pictures Per Second (PPS) – NTSC / 25 Pictures Per Second (PPS) - PAL
Motion Detection Up to 15 Regions Per Channel / Adjustable Sensitivity
Recording Mode Continuous, Motion Detection, Sensor, Scheduled Recording
Digital Signature Supports Digital Signature Verification
Emergency Agent Transmitted through TCP/IP – SCS
Dimensions (h x w x d) 7” x 17.3” x 21.75” (180mm x 440mm x 552mm)
Weight
47-52 lbs (21.3-23.5 kg)
64 - 84 lbs (29-38 kg) with packaging
