Toshiba Surveillix XVS Series - Manual (Page 21)

21
16 Channel (240)
16 Channel (240V)
BNC Connectors for Video Input
Cooling Fan
AC Power Connector
Looping Output Termination
Fire Wire
Audio
• Line In – line level
• Speaker Out
• Microphone In – not used
Sensors Inputs
SVGA Output
PS/2 Mouse Input
PS/2 Keyboard Input
DVI-D Port
Adapter for BNC Looping Output Cable
USB Ports
Control Outputs
Network Port
RCA Video Out
RS-485 Interface
DVI-D
1394
BNC Connectors for Video Input
Cooling Fan
AC Power Connector
Looping Output Termination
Fire Wire
Audio
• Line In – line level
• Speaker Out
• Microphone In – not used
Sensors Inputs
SVGA Output
PS/2 Mouse Input
PS/2 Keyboard Input
DVI-D Port
Adapter for BNC Looping Output Cable
USB Ports
Control Outputs
Network Port
RCA Video Out
RS-485 Interface
Audio Inputs
