65
(E) 46/52/62HMX85
Television System
NTSC standard
Channel Coverage
VHF: 2 through 13
UHF: 14 through 69
Cable TV: Mid band (A-8 through A-1, A through I)
Super band (J through W)
Hyper band (AA through ZZ, AAA, BBB)
Ultra band (65 through 94, 100 through 125)
Power Source
120 V AC, 60 Hz
Power Consumption
190 W (average)
Audio Power
20 W + 20 W
Speaker Type
Main: Two 4 inches (10 cm) round
Tweeter: Two 1-5/8 inches (4 cm) round
Video/Audio Terminals
S-VIDEO INPUT
Y : 1 V(p-p), 75 ohms, negative sync.
C : 0.286 V(p-p) (burst signal), 75 ohms
VIDEO/AUDIO INPUT
VIDEO: 1 V(p-p), 75 ohms, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent,
22 k ohms or greater)
ColorStream ® (component video) INPUT
Y : 1V(p-p), 75 ohms
P
R : 0.7 V(p-p), 75 ohms
P B : 0.7 V(p-p), 75 ohms
AUDIO: 150 mV(rms), 22 k ohms or greater
VIDEO/AUDIO OUTPUT
VIDEO: 1 V(p-p), 75 ohms, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent,
2.2 k ohms or less)
VARIABLE AUDIO OUTPUT
0–300 mV(rms) (30% modulation equivalent,
2.2 k ohms or less)
HDMI INPUT:
HDMI compliant (type A connector)
HDCP compliant
E-EDID* compliant
Suggested scan rates: 1080i, 480p, 480i, 720p
HDMI Audio: 2-channel PCM
32/44.1/48 kHz sampling frequency
16/20/24 bits per sample
Specifications
Note:
• This model complies with the specifications listed below.
• Designs and specifications are subject to change without notice.
• This model may not be compatible with features and/or specifications that may be added in the future.
Dimensions
46HMX85: Width XX-X/X inches (X,XXX mm)
Height XX-X/X inches (XXX mm)
Depth XX-X/X inches (XXX mm)
52HMX85: Width 58-3/8 inches (1,483 mm)
Height 35-1/16 inches (890 mm)
Depth 15-1/4 inches (387 mm)
62HMX85: Width 67-1/16 inches (1,703 mm)
Height 40-15/16 inches (1,040 mm)
Depth 18-3/16 inches (462 mm)
Mass
46HMX85: XX lbs (XX.X kg)
52HMX85: 83 lbs (38 kg)
62HMX85: 99 lbs (45 kg)
Supplied Accessories
Remote Control with 2 size “AA” alkaline batteries
Owner’s Manual (this book)
Important notes sheet
Optional TV Stand
Please contact your authorized Toshiba dealer or visit the
Toshiba Canada web site at www.toshiba.ca to
determinethe appropriate stand for your television.
Operating condition
Temperature: 41°F–95°F (5°C–35°C)
* E-EDID = Enhanced-Extended Display Identification
WARNING: RISK OF ELECTRIC SHOCK!
Never attempt to service the TV yourself. Opening and removing the covers may expose you to
dangerous voltage or other hazards. Refer all servicing to a Toshiba Authorized Service Center.
NOTICE OF POSSIBLE TV STAND INSTABILITY
CAUTION: This television is for use only with
Toshiba television stands specifically
designed for this television model.
Please contact your authorized Toshiba dealer or visit the
Toshiba Canada web site at www.toshiba.ca to determine
the appropriate stand for your television.
