PKG-SVX14A-EN

19

electrical

requirements

Installation

Supply Power Wiring

It is the installer’s responsibility to provide

power supply wiring to the unit terminal

block or the non-fused disconnect switch

option. Wiring should conform to NEC and

all applicable code requirements.

1. Verify the power supply available is

compatible with the unit nameplate

ratings. The supply power must be

within 10%of the rated voltage listed on

the unit nameplate.

2. Reference the electrical data in Table I-

ER-1. Protect the electrical service from

over current and short circuit

conditions in accordance with NEC

requirements. Size protection devices

according to the electrical data on the

unit nameplate.

3. If using a field-supplied disconnect,

install it at or near the unit in

accordance with NEC. Do not mount a

field-supplied disconnect on the unit.

Reference the electrical service

entrance location on unit submittals.

4. Complete the unit power wiring

connections onto either the main

terminal block or the field-provided non-

fushed disconnect switch.

5. Provide proper unit grounding in

accordance with local and national

codes.

Electrical Data Calculations

RLA = rated load amps

Compressor LRA = locked rotor amps

Fan motor LRA = locked rotor amps,

N.E.C. Table 430 - 151

FLA = Full load amps, N.E.C.

Table 430 - 150

Voltage utilization range is ±10%
Minimum circuit ampacity (MCA)

= 1.25 x largest motor amps (FLA or

RLA) + the sum of the remaining motor

amps.
Maximum fuse size (MFS) and maximum

circuit breaker size (MCB) = 2.25 x largest

motor amps (FLA or RLA) + the sum of

the remaining motor amps.
Note: If the rating value determined does

not equal a standard current rating of

over current protective device, use the

next lower standard rating for the

marked maximum rating.
Voltage Range

Voltages must be within +- 10% the

nameplate voltage. Ensure the unit

voltage is balanced by measuring at the

compressor terminals. Voltage imbalance

on three phase systems can cause motor

overheating and premature failure.

Maximum allowable imbalance is 2.0%.
Voltage Imbalance

Read the voltage at the compressor

terminals to determine if it is balanced.

Voltage imbalance on three phase

systems can cause motor overheating

and premature failure. The maximum

allowable imbalance is 2.0%. Voltage

imbalance is defined as 100 times the

sum of the deviation of the three voltages

from the average (without regard to sign)

divided by the average voltage. For

example, if the three measured voltages

are 221, 230, and 227, the average

voltage would be:

(221 + 230 + 227) = 226 volts

3

The percentage of voltage imbalance is

then:

100 * (226-221) = 2.2%

226

In this example, 2.2% imbalance is not

acceptable. Whenever a voltage

imbalance of more than 2.0% exists,

check the voltage at the unit disconnect

switch. If the imbalance at the unit

disconnect switch does not exceed 2.0%,

faulty unit wiring is causing the

imbalance. Conduct a thorough

inspection of the unit electrical wiring

connections to locate the fault, and make

any repairs necessary.

WARNING

Live Electrical Components!

During installation, testing, servicing,
and troubleshooting this equipment, it
may be necessary to work with live
electrical components. Have a
qualified licensed electrician or other
individual who is properly trained in
handling live electrical components
perform these tasks. Failure to follow
all electrical safety precautions when
exposed to live electrical components
could result in death or serious injury.

WARNING

Hazardous Voltage!

Disconnect all electric power,
including remote disconnects before
servicing. Follow proper lockout/
tagout procedures to ensure power
cannot be inadvertently energized.
Failure to disconnect power before
servicing could result in death or
serious injury.

CAUTION

Use Copper Conductors Only!

Unit terminals are not designed to
accept other type conductors. Failure
to use copper conductors may result
in equipment damage.

WARNING

Ground Wire!

All field-installed wiring must be
completed by qualified personnel.
All field-installed wiring must
comply with NEC and applicable
local codes. Failure to follow this
instruction could result in death
or serious injuries.

WARNING

Grounding Required!

Follow proper local and state elec-
trical code on requirements for
grounding. Failure to follow code
could result in death or serious in-
jury.
