3
MODELS 12190, 12191 & 12193 3HP, 5HP & 6.5HP MODEL TILLERS
HANDLEBARS, CLUTCH CABLES AND HANDLEBAR MOUNTING HARDWARE
REF PART
No. No. DESCRIPTION QTY.
REF PART
No. No. DESCRIPTION QTY.
1 1916909 Handlebar, Upper (A) – Incl. Ref.
Nos. 2 ........................................ 1
1916996 Handlebar, Upper (B), (C) – Incl. Ref.
Nos. 2 and 28............................. 1
2 1916928 Decal–Forward Clutch Bail ............ 1
3 9854 Curved Hd. Screw,
5/16-18 x 1-1/2 .......................... 6
4 1100806 Hex Screw, 1/4-20 x 1-1/4............. 1
5 55044 Bracket, Forward Clutch Cable....... 1
6 1916106001 Bail, Forward Clutch ...................... 1
7 9855 Screw, #10-24 x 2 ......................... 1
8 1916712 Spring, Forward Clutch.................. 1
9 1100242 Lockwasher, 5/16 .......................... 6
10 1186230 Hex Nut, 5/16-18 ........................... 6
11 9811 Hex Locknut, 1/4-20 ...................... 1
12 55048 Cable Assembly, Forward Clutch ... 1
13 1100068 Hex Screw, 3/8-16 x 3/4 ................ 2
14 9837 Hex Locknut, 3/8-16 ...................... 2
15 1107383 Flat Washer, 3/8............................. 2
16 1100044 Hex Screw, 5/16-18 x 3/4 .............. 2
17 1902173001 Support, Handlebar ....................... 2
18 1110107 Hex Locknut, 5/16-18 .................... 2
19 1902174001 Handlebar, Lower........................... 1
20 9386 Klip Ring........................................ 1
21 9856 Clevis Pin....................................... 1
22 9552 Hex Screw, 1/4-20 x 1/2,
Self-Tapping (A) ........................ 4
9552 Hex Screw, 1/4-20 x 1/2,
Self-Tapping (B), (C) ................. 6
23 1901273001 Panel ............................................. 1
24 1916923 Decal–Model Name/Logo (A) ........ 1
1916924 Decal–Model Name/Logo (B) ........ 1
1916925 Decal–Model Name/Logo (C)......... 1
25 1916674001 Bracket, Reverse Clutch
Cable (B), (C) ............................. 1
26 1916719 Cable Assembly, Reverse
Clutch (B), (C)............................ 1
27 1186227 Hex Nut, #10-24 ............................ 1
28 1916929 Decal–Reverse Drive Control (B), (C) 1
29 1735531 Cable Tie (B), (C) ........................... 2
(A) Model 12190 – 3HP
(B) Model 12191 – 5HP
(C) Model 12193 – 6.5 HP
