Page 13
TANDBERG 1000/550 for Cisco
CallManager
13
Installation
Power Cable
• Connect the power supply to the ‘DC in’ input on the system.
• Connect the power cable to the power supply.
• Connect the power cable to an electrical distribution socket.
LAN Cable
• To use the system on LAN, connect a LAN cable from the ‘Ethernet’ connector on the system to your LAN.
Wireless LAN - Insert PC Card
• Remove the “dummy” card by pressing the ‘Eject’ button next to the slot.
• Insert the Wireless LAN PC Card.
M
AKE
SURE
YOU
INSERT
THE
CARD
IN
THE
RIGHT
DIRECTION
(
WITH
THE
PRODUCT
LOGO
POINTING
UPWARDS
). P
USH
THE
CARD
INTO
THE
SLOT
UNTIL
THE
‘E
JECT
’
BUTTON
POPS
UP
.
See ‘Wireless LAN Settings’ for configuration.
NOTE
