Top Innovations SF-226 - Manual (Page 9)

9 Top Innovations, Inc.
A
SSEMBLING THE
H
ANDHELD
S
TEAM
C
LEANER
CONNECTING SQUEEGEE
1. Connect Squeegee to Wide Nozzle by inserting hook tabs on
bottom of Squeegee (FIGURE 6-A) into slots on bottom of
Wide Steam Nozzle (FIGURE 6-B).
2. Swing Squeegee backwards until hook latch on back snaps
over tab on top of Wide Nozzle.
3. Connect Wide Nozzle to Steam Nozzle as normal (refer to
Page 7 for more details).
USING CLOTH COVER
1. Stretch Cloth Cover around Wide Nozzle (FIGURE 7). Cloth
Cover should fit snugly enough to stay in place while
steaming.
2. Connect Wide Nozzle to Steam Nozzle as normal (refer to
Page 7 for more details).
FIGURE 6
FIGURE 7
A
B
