RAID Information
Item Description
RAID Level
Shows the current RAID configuration.
Total Capacity Total capacity of the current RAID.
Status Indicates status of the RAID. Can read either Healthy,
Degraded, or Damaged.
Used Percentage Indicates total percentage used of the RAID volume.
Stripe Size Indicates the current stripe size being used.
Remaining Time Indicates the time remaining until the RAID volume is built.
Config Press this to configure RAID volumes.
RAID Configuration
On the RAID List screen, press the RAID
Config button to go to the RAID
Configuration screen. In addition to RAID
disk information and status, this screen lets
you make RAID configuration settings.
For more information on RAID, see
Appendix C: RAID Basics .
RAID Level
You can set the storage volume as JBOD, RAID 0, RAID 1, or RAID 5. RAID
configuration is usually required only when you first set up the device. A brief
description of each RAID setting follows:
RAID Levels
Level Description
JBOD
The storage volume is a single HDD with no RAID support. JBOD
requires a minimum of 1 disk.
RAID 0 Provides data striping but no redundancy. Improves
performance but not data safety. RAID 0 requires a minimum of
2 disks.
RAID 1 Offers disk mirroring. Provides twice the read rate of single
disks, but same write rate. RAID 1 requires a minimum of 2
disks.
RAID 5 Data striping and stripe error correction information provided.
Excellent performance and good fault tolerance. RAID 5 requires
a minimum of 3 disks. RAID 5 can sustain one failed disk.
WARNING
If the administrator improperly removes a hard disk that should not be removed
when RAID status is Degraded, all data will be lost.
27
