Storage Management
The Storage Menu displays the status of storage devices installed in the M3800,
and includes storage configuration options such as RAID and disk settings, folder
configuration settings.
SATA Information
From the Storage menu, choose the SATA
item and the Disks Information screen
appears. From here, you can see various
items about installed SATA hard disks. Blank
lines indicate that a SATA hard disk is not
currently installed in that particular disk slot.
If there is a problem with a disk, a Failed
message will be displayed in the Status
column.
Disks Information
Item Description
Disk No.
Indicates disk location.
Capacity Shows the SATA hard disk capacity.
Model Displays the SATA hard disk model name.
Firmware Shows the SATA hard disk firmware version.
Status Indicates the status of the disk. Can read OK, Warning, or
Failed.
Total Capacity Shows the total SATA hard disk capacity.
Disk Power
Management
The administrator can set the disk to power down after a period
of inactivity.
NOTE
When the Status shows Warning, it usually means there are b
disk. It is shown only as a precaution and you should consi
ad sectors on the hard
der changing the drives.
eSATA Information
From the Storage menu, choose the
eSATA item and the eSATA Information
screen appears. From here, you can see
various items about the eSATA hard disk
connected to the M3800, including capacity,
used percentage, and model and firmware
version. You can even format the connected
eSATA hard disk from this menu.
