Eth. Out & DC Out: Shielded RJ-45 Jack
Pinout for Eth. Out: Power (+) on pins 7+8, ground (-) on pins 4+5 and eth. data on pins 1,2,3 & 6
Indicators:
2 LEDs to indicate power and a connection to radio
Protection:
Resettable fuse for DC input
Integrated Antenna (M900S-SU and M900S-SU-EXT)
Type:
Air-loaded
Patch
Antenna
Polarization:
Vertical
or
Horizontal Polarization, electrically selectable
Frequency:
902
to
928
MHz
Gain:
+10
+/-
1
dBiL
Az Beamwidth:
60º (3 dB pts)
El Beamwidth:
60º (3 dB pts)
Cross Pol:
>15 dB
Front/Back Ratio:
12 dB
VSWR:
<
2.0:1
over
Bandwidth
