G8000MM UPS
Specifications
Model Number
T80M3K-
10KK6XSN
T
80M3K-
15KK6XSN
T80M3K-
22KK6XSN
T
80M3K-
30KK6XSN
T
80M3K-
37KK6XSN
T80M3K-
50KK6XSN
T80M3K-
62KK6XSN
T
80M3K-
75KK6XSN
Capacity
KVA/KW
100/80
150/120
225/180
300/270
375/338
500/450
625/562
750/675
Topology
True On-Line, Double Conversion, IGBT PWM
Input
Voltage
AC Input: 480 V, Three-Phase, Three-Wire + Ground;
Bypass Input: 480 V, Three-Phase, Four-Wire + Ground
Voltage Range
480 V, +15% to -15% (408 to 552 V Without Utilizing Battery) (Optional 600 V)
Power Factor
> 0.98
Current THD
< 6% at 100% Load, 9% Maximum at 50% Load
Frequency
60 Hz, ± 5%
Walk-In
5 to 30 Seconds (Adjustable)
Output
Voltage
480/277 V (600/346 V Optional), Three-Phase, Four-Wire + Ground
Frequency
60 Hz, ±0.05% in Free-Running Mode
Voltage Regulation
±1%
Power Factor
0.8 Nominal
0.9 Nominal
Voltage THD
2% Maximum THD at 100% Linear Load
5% Maximum THD at 100% Non-Linear load
Transient Response
±2% Maximum THD at 100% Step Load
±1% Maximum at Loss/Return of AC Power
±5% Maximum at Load Transfer to/from Static Bypass
Transient Recovery
Less than 20 ms
Voltage Unbalance
1% Maximum at 100% Unbalanced Load
Phase Displacement
1º Maximum at 100% Load
Overload (Inverter)
125% for 10 Minutes; 150% for 1 Minute
Overload (System)
1000% for One Cycle
(Available with Bypass)
Maximum 500% for One Cycle (Available with Bypass)
Battery
Type
Lead Acid (VRLA or Flooded)
Nominal Voltage
480 VDC
Minimum voltage
400 VDC
DC Ripple Voltage
< 2%
Charge Current (A
DC
)
10
15
22.5
30
37.5
50
62.5
75
Number of Cells
240
Environment Cooling
Forced Air
Temperature Range
32º to 104ºF (0º to 40 ºC) During Operating and Storage
Relative Humidity
5% to 95% Non-Condensing
Heat Rejection
(BTU/h)
19,000
28,000
43,000
59,000
74,000
89,000
112,000
134,000
Efficiency
93.5%
93.5%
93.5%
94%
94%
94%
94.5%
94.5%
Altitude
0 to 9000 ft.
Audible Noise
< 64 dbA at 1 m
< 75 dbA at 1 m
Dimensions
Width
43.3”
47.2”
55.1”
76.8”
114.2”
129.9”
Depth
29.8”
37.7”
49.5”
Height
79.7”
Weight
2061 lbs.
2579 lbs.
3263 lbs.
4564 lbs.
4916 lbs.
6923 lbs.
9193 lbs.
Features
Dual-Input Feed, Output Isolation Transformer, RS232 and Dry Contact Interface, Modular Design for Parallel Operation
Standards
UPS: UL1778, CUL, NEMA, PE1, NEC, ISO9001, ANSI C62.41 (IEEE 487)
Tie-Cabinet: NEMA PE2, UL 981, UL 1558
Warranty
1 Year on UPS Electronics Standard, Up to 5 Years Available; 3 Years on Batteries with Startup Purchase;
See Toshiba Warranty Policy for Full Details
Service
24-Hour, 365-Day Technical Support 1-877-867-8773
