Replaceable Parts
30 80A03 TekConnect Probe Interface Module Instruction Manual
Replaceable parts list
Fig. &
index
number
Tektronix part
number Serial no.
effective Serial no.
discont’d
Qty Name & description
Mfr.
code
Mfr. part number
12--1 200--4827--00 1 COVER; EXTERIOR,AL;GOLDEN GATE,SAFETY CON-
TROLLED
TK1943 200--4827--00
12--2 174--4856--00 2 CA,ASSY;SP,ELEC,SEMI--RIGID COAX, 0.141 OD,PLATED 060D9 174--4856--00
12--3 407--4954--00
426--2609--00
1
1
BRACKET ASSY,TEKCONNECT;ACQUISITION,AL
RECEPTACLE; PROBE ASSEMBLY
TK1943 407--4954--00
12--4 386--7392--00 1 PLATE,STRAIN RELIEF; EXTENDER CABLE 386--7392--00
12--5 343--1684--00 1 CLAMP,CABLE RETENTION TK1943 343--1684--00
12--6 174--4855--00 1 CA ASSY; SP, ELEC, 28--26 AWG, 6 COAX WIRES,39 INCH
LONG
060D9 174--4855--00
12--7 348--0430--00 1 BUMPER,PLASTIC; POLYURETHANE,BLACK 2K262 ORDER BY
DESCRIPTION
12--8 105--1132--00 1 LEVER,EJECT; 0.048 THK SST,ELECTRICAL HEAD TK1943 105--1132--00
12--9 386--7393--00 1 PLATE,MOUNTING; AL TK1943 386--7393--00
12--10 441--2328--00 1 CHASSIS, MAIN ASSEMBLY TK1943 441--2328--00
12--11 671--5711--50 1 CIRCUIT BD ASSY, FOR SERVICE ONLY 80009 671--5711--50
12--12 131--6417--00 1 CONTACT,ELEC; GROUNDING,0.600 L X 0.250 W X 0.220
D,ELECTROLESS NICKEL PLATE
TK6457 131--6417--00
12--13 214--4892--00 1 SPRING,TORSION; 0.126 OD,0.094 ID,DOOR,LEFT,0.018
DIA,MUSIC WIRE
8X345 R07SPRG3
12--14 214--4892--00 1 SPRING,TORSION; 0.126 OD,0.094 ID,DOOR,LEFT,0.018
DIA,MUSIC WIRE
8X345 R07SPRG3
12--15 200--4560--00 1 COVER; ELECTRICAL SLOT,0.031 TK1943 200--4560--00
12--16 441--2326--00 1 CHASSIS ASSY; MODULE TK1943 441--2326--00
12--17 214--4891--00 1 SPRING,TORSION; 0.304 X 0.256 X 1.152,EJECT,0.024
DIA,MUSIC WIRE
8X345 214--4891--00
STANDARD ACCESSORIES
Not
shown
174--4857--00 1 CA ASSY;SP, ELEC,SEMI--RIGID COAX, 0.141 OD,PLATED 060D9 174--4857--00
Not
shown
171--1298--xx 1 MANUAL,TECH:INSTRUCTION,80A03 80009 171--1298--00
