80A03 TekConnect Probe Interface Module Instruction Manual 23
Specifications
This section lists the electrical, environmental, and physical characteristics of the
80A03 TekConnect Probe Interface Module.
Specifications listed in this section are guaranteed unless labeled “typical.”
Typical specifications are provided for your convenience and are not guaranteed.
The electrical characteristics listed in Table 4 are valid when the 80A03
TekConnect Probe Interface Module operates within the environmental condi-
tions listed in Table 5 on page 23.
Table 4: Electrical characteristics
Characteristic Description
Output Impedance, nominal 50
Ω 1
Frequency range
2
, typical DC to >12 GHz
Insertion Loss
3
, typical DC to 6 GHz:
<0.4 dB
DC to 12 GHz <0.6 dB
Return Loss
3
, typical DC to 6 GHz:
>25 dB
DC to 12 GHz
>20 dB
Electrical Delay
3
, nominal 0.90 ns
Extender Delay, nominal 5 s
1
Provided by the sampling module input.
2
TekConnect adapter.
3
TekConnect adapter to electrical sampling module. Does not include probe or
sampling module extender.
Table 5: Environmental characteristics
Characteristic Description
Temperature Range
Operating 10
_C to 40 _C (50 _F to 104 _F)
Nonoperating --22
_C to +60 _C (--7.6 _F to 140 _F)
Humidity
Operating 20 to 80% RH, noncondensing
Nonoperating 5 to 90% RH, noncondensing
