Getting Started
80A03 TekConnect Probe Interface Module Instruction Manual 9
Performing a Functional Check
To verify that the 80A03 TekConnect Probe Interface Module is functioning
properly, perform the following procedure.
Refer to Table 2 for a list of recommended equipment.
Table 2: Recommended equipment for performing a functional check
Item description Recommended example
Sampling oscilloscope Tektronix CSA8000 or TDS8000
Sampling module Tektronix 80E02, 80E03, or 80E04
TekConnect probe Tektronix P7000 Series
Probe tip adapter Tektronix P7225, P7240: 015-0678-xx
Tektronix P7260: 067-1456-xx
Tektronix P7330, P7350: 067-0419-00
Semi-rigid SMA cables (2) Tektronix part number 174-4857-xx
SMA cable Tektronix part number 174-1427-00
50
Ω termination, SMA-type
Tektronix part number 015-1022-xx
Torque wrench SMA 5/16, 8 in-lb
To verify the functionality of Channel A, perform the following tasks:
1. Initialize the system:
a. Power on the sampling oscilloscope.
b. Wait for the boot up process to complete.
c. Press the front panel Default Setup button.
2. Connect the signal source:
a. On the sampling oscilloscope, connect the SMA cable to the Internal
Clock Output. See Figure 7 on page 10 for details.
b. Connect the Probe Tip Adapter with 50
Ω termination to the other end of
the SMA cable.
3. Set up the trigger system:
a. In the UI application toolbar, select Internal Clock from the Trig List
menu box.
