119077.01 TELEPRESENCE T3 ROOM INSTALLATION GUIDE 12.08
TANDBERG
Telepresence T3
Note! These items are included in the Immersive Room Package.
What to unpack: Unpack the box marked
• Main Lighting T3
box contents:
• The box contains 6 Fluorescent lightbulbs
US: 21W 830
EU: 39W 830
11 35W Halogen lightbulbs.
The rear ceiling lighting consists of seven 640 mm spot light armatures mechanically
fastened together and parallel wired together. (Rear edge 5 cm / 2” inner rear wall and
228 cm / 7’ 5
3 ⁄
4
” from the floor. )
The front ceiling lighting consists of four 450 mm spot light armatures plus three fluorescent
light armatures mechanically fastened together and parallel wired together. (Rear edge
200 cm / 6’6
7 ⁄
10
” from inner rear wall and bottom edge 228 cm / 7’ 5 3 ⁄
4
” from the floor).
Ceiling attachment by means of hang wires provided with lighting. Anchor method in
ceiling will depend on ceiling structure and composition.
ROOM INSTALLATION GUIDE
MAIN LIGhTING
