LEDs
Page 27
LEDs
The front panel of the modem provides the LEDs shown in Table 2-7.
Table 2-7. Modem LEDs
LED Color Description
Power Green Power
RTS Yellow Request To Send
CTS Yellow Clear To Send
TxD Yellow Transmit Data
RxD Yellow Receive Data
DCD Yellow Carrier Detect
ALB Red* Analog Loopback
DLB Red* Digital Loopback
* When the modem is in remote loopback, both the ALB
and DLB LEDs go ON.
