Configuring the Modem
Page
19
SW1-1 through SW1-4
− Transmit Level (high- & low-speed modes)
Switches SW1-1 through SW1-4 adjust the modem’s transmit level.
Table 2-4 shows the transmit levels you can select using these switches.
Table 2-4. Transmit Levels (High-Speed and Low-Speed Modes)
SW1-1 through SW1-4 Switch Settings
Transmit Level
SW1-1
SW1-2
SW1-3
SW1-4
0 dBm
OFF
OFF
OFF
OFF
−1 dBm
OFF
OFF
OFF
ON
−2 dBm
OFF
OFF
ON
OFF
−3 dBm
OFF
OFF
ON
ON
−4 dBm
OFF
ON
OFF
OFF
−5 dBm
OFF
ON
OFF
ON
−6 dBm
OFF
ON
ON
OFF
−7 dBm
OFF
ON
ON
ON
−8 dBm
ON
OFF
OFF
OFF
−9 dBm
ON
OFF
OFF
ON
−10 dBm
ON
OFF
ON
OFF
−11 dBm
ON
OFF
ON
ON
−12 dBm
ON
ON
OFF
OFF
−13 dBm
ON
ON
OFF
ON
−14 dBm
ON
ON
ON
OFF
+3 dBm
ON
ON
ON
ON
