1-1
Description
The DEM-DAI3010 is an evaluation board for the PCM3010 (24-bit, 96-kHz
ADC and 192-kHz DAC, stereo codec). This board includes not only the
PCM3010 but also analog I/O terminals, analog filter circuits, and an S/PDIF
digital I/O circuit that is useful for codec evaluation. S/PDIF I/O circuits consist
of a 24-bit/96-kHz digital audio interface receiver (DIR1703) and a digital audio
interface transmitter (DIT4096), and include optical (TOSLINK) and coaxial
S/PDIF digital I/O connectors. Removing shorting plugs from the pins of a
header breaks the connection between the S/PDIF I/O circuits and the
PCM3010for easier PCM3010 device evaluation.
Topic Page
1.1 Block Diagram 1-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Use of the DEM-DAI3010 1-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 Settings and Connections for Basic Operation 1-4 . . . . . . . . . . . . . . . . . .
1.4 Setting Functions 1-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 1
