29
Performance
Data
SSP-PRC002-EN
Table PD-23— Discharge Plenum And Grille Assembly Throw Distance — Air Handler — ft (m)
Unit Louver Angle Deflection Position
Model No. CFM m 3 /h Straight 20 40 55
1400 2378 38 (11.6) 24 (7.3) 22 (6.7) 18 (5.5)
1600 2718 42 (12.8) 31 (9.4) 26 (7.9) 20 (6.1)
TWE050 1800 3058 46 (14.0) 37 (11.3) 29 (8.8) 22 (6.7)
2000 3398 48 (14.6) 43 (13.1) 33 (10.1) 24 (7.3)
2200 3737 51 (15.5) 50 (15.2) 36 (11.0) 25 (7.6)
2100 3568 49 (14.9) 38 (11.6) 31 (9.4) 27 (8.2)
2400 4077 52 (15.9) 43 (13.1) 35 (10.7) 29 (8.8)
2700 4587 55 (16.8) 48 (14.6) 38 (11.6) 31 (9.4)
TWE075 3000 5097 58 (17.7) 53 (16.2) 42 (12.8) 32 (9.8)
3200 5436 56 (17.1) 46 (14.0) 38 (11.6) 30 (9.1)
3600 6116 62 (18.9) 51 (15.5) 42 (12.8) 33 (10.1)
4000 6795 66 (20.1) 57 (17.4) 47 (14.3) 35 (10.7)
4400 7475 71 (21.6) 62 (18.9) 52 (15.9) 38 (11.6)
TWE100 4800 8154 76 (23.2) 67 (20.4) 56 (17.1) 42 (12.8)
4300 7305 42 (12.8) 32 (9.8) 29 (8.8) 21 (6.4)
4900 8324 47 (14.3) 38 (11.6) 32 (9.8) 25 (7.6)
5400 9174 52 (15.9) 44 (13.4) 37 (11.3) 29 (8.8)
TWE155 5600 9514 50 (15.2) 40 (12.2) 33 (10.1) 27 (8.2)
6000 10193 57 (17.4) 49 (14.9) 41 (12.5) 32 (9.8)
6400 10873 56 (17.1) 46 (14.0) 38 (11.6) 30 (9.1)
7200 12232 62 (18.9) 51 (15.5) 42 (12.8) 33 (10.1)
TWE200 8000 13591 66 (20.1) 57 (17.4) 47 (14.3) 35 (10.7)
Throw distance values are based on a terminal velocity of 75 FPM (0.38 m/s).
Throw distance values at other terminal velocities may be established by multiplying throw distances in table above by throw
factor:
Terminal Velocity Throw Factor
50 fpm (.25 m/s) x 1.50
100 fpm (.51 m/s) x .75
150 fpm (.76 m/s) x .50
Table PD-24— Static Pressure Drop Through Accessories (Inches Of Water Column) 1 — Air Handler
Discharge Electric Heaters (kW)
Unit Return Grille Plenum and Grille 2 5-10 15-20 25-30 35-50
Model No. CFM m 3 /h In. wc 1 Pascal In. wc 1 Pascal In. wc (Pascal)
1400 2380 .09 (22.4) .16 (39.8) .06 (15.0) .06 (15.0) .12 (29.9) —
TWE050A 1600 2718 .12 (29.9) .21 (52.3) 08 (19.9) .08 (19.9) .14 (34.9) —
2000 3398 .18 (44.8) .33 (82.2) .13 (32.4) .13 (32.4) .19 (47.3) —
2100 3568 .05 (12.5) .19 (47.3) .02 (5.0) .03 (7.5) .05 (12.5) .08 (19.9)
TWE075A 2400 4079 .08 (19.9) .27 (67.2) .03 (7.5) .06 (15.0) .08 (19.9) .12 (29.9)
3000 5098 .13 (32.4) .40 (99.6) .06 (15.0) .12 (29.9) .17 (42.4) .23 (57.3)
TWE100A 2800 4756 .04 (10.0) .34 (84.7) .03 (7.5) .04 (10.0) .14 (34.9) .20 (49.8)
TWE100B 3200 5436 .07 (17.4) .43 (107.1) .06 (15.0) .13 (32.4) .19 (47.3) .26 (64.8)
4300 7304 .07 (17.4) .18 (44.8) .02 (5.0) .02 (5.0) .04 (10.0) .05 (12.5)
TWE155B 4800 8154 .09 (22.4) .23 (57.3) .03 (7.5) .03 (7.5) .06 (15.0) .08 (19.9)
6000 10195 .15 (37.4) .34 (84.7) .06 (15.0) .06 (15.0) .12 (29.9) .17 (42.4)
5600 9515 .07 (17.4) .32 (79.7) .04 (10.0) .04 (10.0) .10 (25.0) .15 (37.4)
TWE200B 6400 10872 .11 (27.4) .43 (107.1) .06 (15.0) .06 (15.0) .13 (32.4) .19 (47.3)
8000 13594 .17 (42.3) .66 (164.3) .10 (25.0) .10 (25.0) .20 (49.8) .30 (74.7)
1. Return air filter ESP included in Fan Performance Table data.
2. At louver opening angle of 42°F (5.5°C). For ESP at other angle openings, see accessory Installer’s Guide.
