16
Performance
Data
SSP-PRC002-EN
(TWA075A)
Table PD-5 — Gross Cooling Performance (kW) TWA075A Heat Pump Only (SI)
OD Temp Suction Reference Temperature °C
°C -1.1 1.7 4.4 7.2 10 12.8
Head pressure (kPA) 1142 1180 1220 1262 1305 1350
18.3 Capacity (kW) 21.2 23.4 25.7 28.1 30.5 33.0
OD Unit Power (kW) 4.91 5.01 5.13 5.25 5.39 5.52
Head pressure (kPA) 1324 1364 1406 1449 1494 1541
23.9 Capacity (kW) 20.6 22.7 24.9 27.1 29.4 31.8
OD Unit Power (kW) 5.42 5.54 5.66 5.80 5.94 6.08
Head pressure (kPA) 1519 1563 1607 1653 1701 1749
29.4 Capacity (kW) 19.8 21.8 23.9 26.0 28.2 30.4
OD Unit Power (kW) 6.01 6.15 6.28 6.42 6.57 6.72
Head pressure (kPA) 1733 1778 1825 1873 1922 1973
35.0 Capacity (kW) 18.8 20.7 22.7 24.7 26.7 28.8
OD Unit Power (kW) 6.71 6.84 6.98 7.12 7.27 7.42
Head pressure (kPA) 1961 2009 2057 2107 2159 2212
40.6 Capacity (kW) 17.6 19.4 21.3 23.2 25.1 27.1
OD Unit Power (kW) 7.48 7.61 7.75 7.89 8.04 8.19
Head pressure (kPA) 2206 2255 2305 2357 2411 2467
46.1 Capacity (kW) 16.4 18.0 19.8 21.5 23.4 25.2
OD Unit Power (kW) 8.32 8.45 8.59 8.72 8.87 9.02
Table PD-5 — Gross Cooling Performance (MBh) TWA075A Heat Pump Only (I-P)
OD Temp Suction Reference Temperature °F
°F 30 35 40 45 50 55
Head press PSIG 166 171 177 183 189 196
65 Cap. Btuh/1000 72.2 79.8 87.7 95.9 104.3 112.8
OD Unit KW 4.91 5.01 5.13 5.25 5.39 5.52
Head press PSIG 192 198 204 210 217 223
75 Cap. Btuh/1000 70.3 77.5 85.0 92.7 100.5 108.5
OD Unit KW 5.42 5.54 5.66 5.80 5.94 6.08
Head press PSIG 220 227 233 240 247 254
85 Cap. Btuh/1000 67.5 74.4 81.5 88.8 96.2 103.7
OD Unit KW 6.01 6.15 6.28 6.42 6.57 6.72
Head press PSIG 251 258 265 272 279 286
95 Cap. Btuh/1000 64.1 70.7 77.4 84.2 91.2 98.3
OD Unit KW 6.71 6.84 6.98 7.12 7.27 7.42
Head press PSIG 284 291 298 306 313 321
105 Cap. Btuh/1000 60.2 66.3 72.6 79.1 85.7 92.5
OD Unit KW 7.48 7.61 7.75 7.89 8.04 8.19
Head press PSIG 320 327 334 342 350 358
115 Cap. Btuh/1000 55.9 61.6 67.5 73.5 79.8 86.2
OD Unit KW 8.32 8.45 8.59 8.72 8.87 9.02
