12
Performance
Data
SSP-PRC002-EN
(System)
Table PD-1 — Gross Cooling Capacities (MBh) TWA075A Heat Pump with TWE075A Air Handler (I-P)
Ambient Temperature (°F)
85 95 105 115
Enter.
Dry
Entering Wet Bulb (°F)
Bulb 61 67 73 61 67 73 61 67 73 61 67 73
CFM (°F) Total Sens. Total Sens. Total Sens. Total Sens. Total Sens. Total Sens. Total Sens. Total Sens. Total Sens. Total Sens. Total Sens. Total Sens.
2250 75 78.1 61.6 86.4 51.4 95.4 35.1 75.4 60.3 83.4 50.1 91.9 33.9 72.3 58.8 79.9 48.7 88.0 32.5 68.7 57.0 75.9 47.1 83.7 31.0
80 78.4 71.9 86.6 59.4 95.4 46.0 75.9 70.6 83.6 58.1 92.0 44.7 72.8 69.1 80.1 56.6 88.1 43.2 69.4 67.4 76.0 54.8 83.7 41.6
85 80.2 80.2 86.7 69.6 95.5 56.5 78.0 78.0 83.7 68.2 92.1 55.2 75.4 75.4 80.2 66.7 88.2 53.8 72.3 72.3 76.3 64.9 83.9 52.2
90 84.3 84.3 87.1 79.9 95.6 67.0 82.0 82.0 84.2 78.6 92.2 65.7 79.3 79.3 80.9 77.0 88.3 64.1 76.1 76.1 77.1 75.4 84.0 62.4
2500 75 79.6 64.6 88.1 50.6 96.9 35.8 76.9 63.2 84.9 49.3 93.4 34.6 73.6 61.6 81.3 47.8 89.3 33.2 69.9 59.8 77.2 46.1 84.8 31.6
80 80.2 75.9 88.2 62.1 97.0 47.5 77.6 74.5 85.1 60.8 93.4 46.2 74.5 73.0 81.4 59.1 89.4 44.7 70.7 70.6 77.3 57.3 85.0 43.1
85 82.9 82.9 88.3 73.2 97.1 59.0 80.6 80.6 85.2 71.8 93.6 57.7 77.8 77.8 81.6 70.2 89.6 56.3 74.6 74.6 77.6 68.5 85.2 54.7
90 87.2 87.2 89.0 84.5 97.1 70.3 84.7 84.7 86.1 83.2 93.7 68.9 81.8 81.8 82.6 81.7 89.7 67.4 78.6 78.6 78.6 78.6 85.3 65.7
2750 75 81.0 67.3 89.4 52.3 98.2 36.5 78.1 65.9 86.1 51.0 94.6 35.1 74.8 64.3 82.4 49.5 90.4 33.7 71.0 62.5 78.2 47.8 85.8 32.0
80 81.8 79.7 89.4 64.6 98.3 48.9 79.1 78.3 86.2 63.2 94.7 47.6 75.7 75.7 82.5 61.6 90.5 46.2 72.5 72.5 78.3 59.8 86.0 44.6
85 85.3 85.3 89.7 76.6 98.4 61.4 82.8 82.8 86.5 75.3 94.8 60.1 79.9 79.9 82.9 73.7 90.7 58.6 76.6 76.6 78.8 71.9 86.2 57.0
90 89.7 89.7 90.8 89.1 98.5 73.5 87.1 87.1 87.8 87.7 94.9 72.1 84.1 84.1 84.2 84.2 90.9 70.6 80.6 80.6 80.7 80.7 86.4 68.9
3000 75 82.1 70.0 90.5 54.0 99.3 36.9 79.2 68.6 87.2 52.6 95.6 35.6 75.8 67.0 83.3 51.1 91.3 34.1 71.9 65.1 79.1 49.4 86.6 32.5
80 82.8 82.8 90.6 67.0 99.4 50.3 80.4 80.4 87.3 65.6 95.7 49.0 77.5 77.5 83.5 64.0 91.5 47.5 74.1 74.1 79.2 62.2 86.9 45.9
85 87.4 87.4 90.9 80.0 99.5 63.7 84.8 84.8 87.7 78.6 95.9 62.4 81.7 81.7 84.0 77.0 91.6 60.7 78.3 78.3 79.9 75.2 87.0 59.0
90 91.9 91.9 92.0 92.0 99.7 76.6 89.2 89.2 89.3 89.3 96.0 75.2 86.0 86.0 86.1 86.1 91.8 73.6 82.5 82.5 82.6 82.6 87.3 71.9
Note: All temperatures are in degrees Fahrenheit. Airflow is in cfm.
Table PD-1— Gross Cooling Capacities (kW) TWA075A Heat Pump with TWE075A Air Handler (SI)
Ambient Temperature (°C)
29.4 35.0 40.6 46.1
Enter.
Dry
Entering Wet Bulb (°C)
Bulb 16.1 19.4 22.8 16.1 19.4 22.8 16.1 19.4 22.8 16.1 19.4 22.8
m 3 /h (°C) Total Sens. Total Sens. Total Sens. Total Sens. Total Sens. Total Sens. Total Sens. Total Sens. Total Sens. Total Sens. Total Sens. Total Sens.
3823 24 22.9 18.0 25.3 15.0 27.9 10.3 22.1 17.7 24.4 14.7 26.9 9.9 21.2 17.2 23.4 14.3 25.8 9.5 20.1 16.7 22.2 13.8 24.5 9.1
27 23.0 21.1 25.4 17.4 27.9 13.5 22.2 20.7 24.5 17.0 26.9 13.1 21.3 20.2 23.4 16.6 25.8 12.7 20.3 19.7 22.3 16.0 24.5 12.2
29 23.5 23.5 25.4 20.4 28.0 16.5 22.8 22.8 24.5 20.0 27.0 16.2 22.1 22.1 23.5 19.5 25.8 15.7 21.2 21.2 22.3 19.0 24.6 15.3
32 24.7 24.7 25.5 23.4 28.0 19.6 24.0 24.0 24.7 23.0 27.0 19.3 23.2 23.2 23.7 22.6 25.9 18.8 22.3 22.3 22.6 22.1 24.6 18.3
4248 24 23.3 18.9 25.8 14.8 28.4 10.5 22.5 18.5 24.9 14.4 27.3 10.1 21.6 18.0 23.8 14.0 26.2 9.7 20.5 17.5 22.6 13.5 24.8 9.2
27 23.5 22.2 25.8 18.2 28.4 13.9 22.7 21.8 24.9 17.8 27.4 13.5 21.8 21.4 23.8 17.3 26.2 13.1 20.7 20.7 22.6 16.8 24.9 12.6
29 24.3 24.3 25.9 21.4 28.4 17.3 23.6 23.6 25.0 21.0 27.4 16.9 22.8 22.8 23.9 20.6 26.2 16.5 21.8 21.8 22.7 20.0 24.9 16.0
32 25.5 25.5 26.1 24.8 28.4 20.6 24.8 24.8 25.2 24.4 27.4 20.2 24.0 24.0 24.2 23.9 26.3 19.7 23.0 23.0 23.0 23.0 25.0 19.2
4672 24 23.7 19.7 26.2 15.3 28.8 10.7 22.9 19.3 25.2 14.9 27.7 10.3 21.9 18.8 24.1 14.5 26.5 9.9 20.8 18.3 22.9 14.0 25.1 9.4
27 24.0 23.3 26.2 18.9 28.8 14.3 23.2 22.9 25.3 18.5 27.7 13.9 22.2 22.2 24.2 18.0 26.5 13.5 21.2 21.2 22.9 17.5 25.2 13.0
29 25.0 25.0 26.3 22.4 28.8 18.0 24.3 24.3 25.3 22.0 27.8 17.6 23.4 23.4 24.3 21.6 26.6 17.2 22.4 22.4 23.1 21.1 25.2 16.7
32 26.3 26.3 26.6 26.1 28.8 21.5 25.5 25.5 25.7 25.7 27.8 21.1 24.6 24.6 24.6 24.6 26.6 20.7 23.6 23.6 23.6 23.6 25.3 20.2
5097 24 24.0 20.5 26.5 15.8 29.1 10.8 23.2 20.1 25.5 15.4 28.0 10.4 22.2 19.6 24.4 15.0 26.7 10.0 21.1 19.1 23.1 14.5 25.4 9.5
27 24.3 24.3 26.5 19.6 29.1 14.7 23.5 23.5 25.6 19.2 28.0 14.4 22.7 22.7 24.5 18.7 26.8 13.9 21.7 21.7 23.2 18.2 25.4 13.4
29 25.6 25.6 26.6 23.4 29.1 18.7 24.8 24.8 25.7 23.0 28.1 18.3 23.9 23.9 24.6 22.5 26.8 17.8 22.9 22.9 23.4 22.0 25.5 17.3
32 26.9 26.9 26.9 26.9 29.2 22.4 26.1 26.1 26.1 26.1 28.1 22.0 25.2 25.2 25.2 25.2 26.9 21.6 24.2 24.2 24.2 24.2 25.6 21.1
Note: All temperatures are in degrees Celsius. Airflow is in liters per second.
