In some industrial applications, users need reliable and efficient adjustable speed drives
that do not contribute significant harmonic distortion to the power grid. The HX7 meets this
need. The HX7 is the newest addition to the Toshiba seven-series family, offering the latest
technology and proven reliability.
• Patented 18-Pulse Design*
• Small Footprint
• Powerful, User-Friendly Operator Interface
• Variety of Communication Options
• Optional Three-Contactor Bypass
• Optional Solid-State-Starter Bypass
1. Small Footprint with
Uniform 24” Depth
2. User-Friendly
Electronic Operator
Interface (EOI)
3. Variety of User
Configurable
Options
4. Gasketed and
Filtered Enclosure is
Force Ventilated
5. Top or Bottom Cable
Entry/Exit
6. 65 KAIC Breaker
7. Proven Toshiba ASD
Technology
8. Integrated Phase-
Shifting Transformer
* US Patent 6396723
JP Patent 2000-179543 (Pending)
1
2
3
4
5
6
7
8
