E6581295⑥
- 17 -
Data composition of output instance 150
Byte bit Specifications 0 1 Supplement
0 0 Fault FL No output Output -
0 1 Fault No trip Tripped
The rtry status and the trip retention
status are also regarded as tripped
statuses.
0 2 Alarm No alarm Alarm issued -
0 3 (Reserved) - - -
0 4
Motor #1/#2
(THR2 selection) Motor #1
(THR1)
Motor #2
(THR2)
Indicates the motor electronic-thermal
protection level selected.
0: Protection level #1 (thr)
1: Protection level #2 (f173)
0 5 PI control
PI control
permission
PI control
prohibition
-
0 6
Acceleration/
Deceleration
#1/#2 selection
(AD2 selection)
Acceleration/
Deceleration #1
(AD1)
Acceleration/
Deceleration #2
(AD2)
Indicates the acceleration/deceleration
time selected.
0: acc, dec
1: f500, f501
0 7 DC braking OFF
Forced DC
braking
-
1 0 JOG run OFF JOG run -
1 1
Forward run/
Reverse run
Forward run Reverse run -
1 2 Run/Stop Stop Run -
1 3 Coasting (ST off) ST=ON ST=OFF -
1 4 Emergency stop
No emergency
stop
Emergency stop -
1 5
Ready for operation
ST=ON Getting ready for
operation
Ready for
operation
ST=ON and RUN=ON in addition to
“ready for operation”*
1 6 Ready for operation
Getting ready for
operation
Ready for
operation *
-
1 7 ** Local/Remote Remote Local -
* Ready for operation: Initialization completed, not a stop due to a failure, no alarm issued, not moff, not a forced stop
due to ll, not a forced stop due to a momentary power failure.
** It is reserved in VF-AS1.
