Performance data — 50 hz (40–60ton) part load – Trane CG-PRC007-EN User Manual
Page 29
29
CG-PRC007-EN
Percent
Entering Condenser Air Temperature (Degrees F)
Load
75
85
95
105
115
120
Percent
Entering Condenser Air Temperature (Degrees F)
Load
75
85
95
105
115
120
EER
14.1
12.2
10.4
8.8
7.4
6.7
100
Capacity
52.2
49.8
47.3
44.5
41.6
40.1
System KW
44.4
49.2
54.6
60.8
67.7
71.4
EER
14.9
12.9
11.0
9.4
7.9
7.2
75
Capacity
40.5
38.7
36.7
34.6
32.4
31.2
System KW
32.7
36.1
40.0
44.4
49.3
52.0
EER
16.2
14.2
12.3
10.5
8.9
8.2
50
Capacity
28.6
27.4
26.1
24.7
23.3
22.5
System KW
21.2
23.2
25.5
28.2
31.2
32.9
EER
15.5
13.4
11.5
9.8
8.2
7.5
25
Capacity
13.8
13.2
12.5
11.8
11.1
10.7
System KW
10.6
11.8
13.0
14.5
16.1
17.0
Percent
Entering Condenser Air Temperature (Degrees F)
Load
75
85
95
105
115
120
EER
14.2
12.3
10.5
9.0
7.5
6.9
100
Capacity
40.4
38.7
36.8
34.8
32.6
31.4
System KW
34.3
37.8
41.9
46.6
51.8
54.6
EER
14.7
12.8
11.0
9.4
7.9
7.3
80
Capacity
33.4
31.9
30.4
28.7
26.9
26.0
System KW
27.3
30.0
33.1
36.7
40.7
42.9
EER
15.5
13.6
11.8
10.1
8.6
7.9
60
Capacity
26.2
25.1
24.0
22.7
21.4
20.7
System KW
20.2
22.1
24.3
26.9
29.7
31.3
EER
14.5
12.6
10.8
9.2
7.7
7.1
30
Capacity
12.4
11.9
11.3
10.7
10.0
9.6
System KW
10.3
11.3
12.6
14.0
15.5
16.4
Notes:
1. Data based on 0.0001 fouling factor at sea level.
2. Interpolation between points is permissible.
3. Extrapolation beyond points is not permissible.
4. EER - Energy Efficiency Ratio (Btu/watt-hour). Power inputs include compressors,
condenser fans and control power
5. Ratings based on evaporator drop of 10°F
6. Rated in accordance with ARI Standard 550/590-98.
7. Data obtained assuming 400 Volt supply.
EER
14.2
12.2
10.3
8.7
7.3
6.6
100
Capacity
32.4
30.9
29.3
27.7
25.9
25.0
System KW
27.4
30.5
34.1
38.2
42.8
45.3
EER
14.9
12.8
10.9
9.2
7.7
7.1
75
Capacity
25.2
24.0
22.8
21.5
20.2
19.5
System KW
20.3
22.5
25.0
27.9
31.3
33.1
EER
16.3
14.2
12.2
10.4
8.8
8.1
50
Capacity
17.8
17.1
16.3
15.4
14.5
14.0
System KW
13.2
14.5
16.0
17.7
19.8
20.9
EER
14.3
12.2
10.3
8.6
7.2
6.5
25
Capacity
8.4
8.0
7.6
7.1
6.7
6.4
System KW
7.1
7.9
8.9
9.9
11.1
11.8
(40–60 Ton)
Part Load
Performance
Data — 50 HZ
Table PD-24— 40 Ton — CGAF-C40
Table PD-25— 50 Ton — CGAF-C50
Table PD-26— 60 Ton — CGAF-C60
