4. Register Configuration
4.2.3 Parameter area
The parameter area of the buffer memory contains the following contents.
Address Address
0 CH1 status 64
1 CH2 status Status and 65
2 CH1 command command 66
3 CH2 command 67
4 Status 1 68
5 RSW1/2 information 69
6 SW1 information 70
7 SW2 information 71 Reserved
8 CH1, CH2 72
9 common 73
10 parameters 74
11 75
12 Command 1 76
13 77
14 78
15 79
16 CH1 receive error 80 CH2 receive error
17 CH1 transmit error 81 CH2 transmit error
18 CH1 channel status 82 CH2 channel status
19 CH1 receive length 83 CH2 receive length
20 84
21 85
22 86
23 87
24 CH1 trailing code 88 CH2 trailing code
25 CH1 time-out check CH1 89 CH2 time-out check CH2
26 parameters 90 parameters
27 91
28 92
29 93
30 94
31 95
63 127
Note: Blanks are for future use. (Reserved)
