3
Set ON time by
HH
,
MM
buttons,
and then push
SET
button.
When push
SET
button, the
flashed ON time (8:00 in example)
change, and OFF time of the
program 1 flashes at the same
time.
WEEKLY TIMER
ERROR
SuMoTuWeTh Fr Sa
PROGRAM1
PROGRAM2
PROGRAM3
CHECK
PROGRAM
SET
DAY
HH
MM
CLEAR
CANCEL
3, 4
3, 4, 5
6
7
Setting to other da y, repeat abo ve pr ocedure fr om
1
to
6
.
If you need to set the same time as previous setting. Refer to “7. How to copy the
program operation time”.
CAUTION
• Setup of the program time :
is treated as
.
(Example) In the following cases, setup are available.
ON time
OFF time
• If 30 seconds have passed while the button is flashing without pushing
DAY
or
HH
/
MM
buttons, the display returns automatically to the original display (Normal display).
In this case, repeat the procedure from the 1st step.
4
Set OFF time by
HH
/
MM
buttons, and then push
SET
button.
When pushing
SET
button, the flashed ON time (12:00 in
example) changes, and ON time of the program 2 flashes.
5
Next set up the operation time to the program 2 and 3.
When pushing
SET
button after OFF time of the program
3 has been set, the flashed OFF time (19:00 in example)
changes and ON time of the program 1 flashes.
6
Finally, push
PROGRAM
button.
Push
PROGRAM
button within 30 seconds after No. 5 step.
Then, one day timer (Monday in example) is set completely.
ON/OFF is displayed when the present time is included
in the range of the set time.
(In the above status, the contents of the program 1 are
displayed as the present time is included in the range from
ON time to OFF time of the program 1.)
PROGRAM1
PROGRAM2
PROGRAM3
PROGRAM1
PROGRAM2
PROGRAM3
PROGRAM1
PROGRAM2
PROGRAM3
PROGRAM1
PROGRAM2
PROGRAM3
6. Set error
If flashing
ERROR
is displayed when the program operation has been set up, correct the
time following the procedure below.
1. When flashing
ERROR
is displayed, ON time of the failed program flashes.
2. Push
SET
button to flash the time to be corrected.
3. Using
HH
/
MM
buttons, correct ON/OFF time.
4. Push
SET
button. When the setup is correctly performed,
ERROR
display disappears.
5. The correction has completed by pushing
PROGRAM
button.
CAUTION
• When ON/OFF time is set as follows,
ERROR
is displayed.
1) When a part of the operation time makes inroads into a part of another operation time
ERROR
SuMoTuWeTh Fr Sa
PROGRAM1
PROGRAM2
PROGRAM3
Example:
ON time
OFF time
2) When OFF time is ahead of ON time
Example:
ON time
OFF time
3) When ON time is same as OFF time
Example:
ON time
OFF time
4) ON time or OFF time is singly set up
Example:
ON time
OFF time
[Is not set]
• The following cases are not set error.
1) OFF time of the previous cycle is same as ON time of the next cycle.
Example:
ON time
OFF time
2) When the next cycle is set to the time before the
set time of the previous cycle
Example:
ON time
OFF time
ON time
OFF time
Pushing the
PROGRAM
button changes the order in order of time.
3) When both ON and OFF times are same
Example:
ON time
OFF time
0:00
23:59
ON
OFF
ON
OFF
0:00
23:59
OFF
ON
0:00
23:59
ON OFF
0:00
23:59
ON
OFF
0:00
23:59
ON
OFF
ON
OFF
0:00
23:59
ON
OFF
ON
OFF
Continuous operation
for 24 hours
