- 118 -

EO1-11116

MA-516-100 SERIES

NOTES

1. Any Bit No. shaded and filled with “-- vacant --” in the Address tables on the following pages

will be disregarded even if it is SET or RESET. (However, if ever SET, it will not result in an
error.)

2. The Initial Status of each Bit is indicated by a dotted frame such as:

If you have never changed the Bit statuses in the Address before, the Initial Status is active.
Therefore, only the Bit status changes of the required Addresses may be entered. If an All
Memory Clear is operated (refer to Chapter “27. Status Clear and Memory Clear
Operations” on page 154), all the Bits in all the Address automatically regain the Initial
Status.

Programming Example)

To select the following options:

Address 1

(refer to the next page)

Bit 1: Time NON-PRINT (SET status)

Bit 2: Purchased Item Count NON-PRINT (SET status)

Other Bits are to be all RESET (PRINT)

Control Lock: BLIND

AT/TL

#/NS

@/FOR
