User’s Manual 2-6
The Grand Tour
Product appearance depends on the model you purchased.
Figure 2-5 The underside of the computer
1. Battery lock 4. Cooling vents
2. Battery release latch 5. Memory module slot
3. Battery pack
Battery lock Slide the battery lock to release the battery pack
ready for removal.
Battery release latch Slide and hold this latch into its "Unlock" position
in order to release the battery pack for removal.
For more detailed information on removing the
battery pack please refer to Chapter 6,
Power
and Power-Up Modes .
Battery pack The battery pack provides power to the computer
when the AC adaptor is not connected. For more
detailed information on the use and operation of
the battery pack please refer to Chapter 6,
Power
and Power-Up Modes .
Cooling vents The cooling vents help the processor to avoid
overheating.
Do not block the cooling vents. Keep foreign metal objects, such as
screws, staples and paper clips, out of the cooling vents. Foreign metal
objects can create a short circuit, which can cause damage and fire,
possibly resulting in serious injury
Memory module slot The memory module slot allows for the
installation, replacement and removal of
additional memory module.
Refer to the Additional memory module section in
Chapter 3, Hardware, Utilities and Options .
