Toshiba M65-S821 - Manual

This product specification is variable and subject to change prior to product launch.
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite M65-S821 Rev. 1.02 2005-12-2 DSM T20051028 CB 1.10 Page 2 of 6
Satellite M65-S821 Detailed Product Specification 1
Model Name Description Part Number UPC
M65-S821 Microsoft® Windows® XP Home, Intel® Pentium® M Processor 740, 512MB DDR2,
120GB (5400 RPM) PATA, 8x DVD SuperMulti (+/-R Double Layer), 17” Widescreen
TruBrite™ WXGA,TV-Out, Intel® Graphics Media Accelerator 900, Intel® PRO/Wireless
2915ABG, CD control buttons, Sunlight Copper, 5-in-1 Bridge Media Adapter,
ExpressCard™, harman/kardon®, 1-year Limited Warranty PSM60U-0CR021 032017492783
M65-S8211 Microsoft® Windows® XP Professional, Intel® Pentium® M Processor 740, 512MB
DDR2, 120GB (5400 RPM) PATA, 8x DVD SuperMulti (+/-R Double Layer), 17”
Widescreen TruBrite™ WXGA,TV-Out, Intel® Graphics Media Accelerator 900, Intel®
PRO/Wireless 2915ABG, CD control buttons, Sunlight Copper, 5-in-1 Bridge Media
Adapter, ExpressCard™, harman/kardon®, 1-year Limited Warranty PSM60U-0CR027 032017492790
Operating System
2
• Microsoft® Windows® XP Professional (S8211)
• Microsoft® Windows® XP Home Edition (S821)
• TOSHIBA Express Media Player
o Quick access for CD and DVD watching
Processor and Chipset
3
Intel® Centrino™ Mobile Technology featuring:
• Intel Pentium® M Processor 740
o 1.73GHz, 2MB L2, 533MHz FSB
• Mobile Intel 915GM Express Chipset
• Intel PRO/Wireless 2915ABG (802.11a/b/g)
Memory
4
• Configured with 512MB DDR2 SDRAM (both memory modules may
be filled)
• 512MB(min)/2048MB (max), 2 memory slots using 256MB, 512MB,
or 1024MB PC4200 DDR2 533MHz SDRAM, dual-channel
support requires two memory modules of same capacity and
clockspeed
Hard Disk Drive
5
• 120GB (5400 RPM); Enhanced IDE (ATA-6) hard disk drive; 9.5mm
height; user removable
Fixed Optical Disk Drive
6
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x:read),
CD-R (24x:write), CD-RW (10x:write), DVD-ROM
(8x:read), DVD-R (Single Layer, 8x:write), DVD-R
(Double Layer, 2x: write), DVD-RW (4x:write), DVD+R
(Single Layer, 8x:write), DVD+R (Double Layer,
2.4x:write), DVD+RW (4x:write), DVD-RAM (5x:write)
Display
7
• 17.0” diagonal widescreen TruBrite™ TFT active-matrix LCD
display at 1440x900 native resolution (WXGA)
Graphics
8
• Intel Graphics Media Accelerator 900 with 8MB-128MB dynamically
allocated shared graphics memory
Sound
• Built-in harman/kardon® stereo speakers
• SRS Labs audio enhancements
9
o SRS TruSurround XT® virtual surround sound
o SRS WOW™ stereo enhancement
• Realtek ALC250 16-bit stereo software sound
o Supports 3D Sound, Direct 3D Sound, DirectSound,
Direct Music, MIDI (playback)
• Sound Volume Control Dial
Input Devices
• Keyboard
o 85 key US keyboard with 10-key
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
• TouchPad™ pointing device
• TouchPad™ Enable/Disable (FN+F9 or by help of software)
• Control Buttons:
o Internet button to launch default browser
o Express Media Player CD/DVD launch button
o CD/DVD control buttons (Skip to Previous/Next Track,
Play, Stop)
Communications
• Toshiba V.92 software modem 10
• Intergraded 10/100 Base-TX Ethernet
• Integrated Intel Pro/Wireless Network Connection 2915ABG
(802.11a/b/g) 11
Expandability
• 2 main memory slots. Both slots may be occupied.
• 1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus™
• ExpressCard™ slot supporting ExpressCard/34 and
ExpressCard/54
• 5-in-1 Bridge Media Adapter
o Secure Digital, Memory Stick™, Memory Stick PRO™,
Multi Media Card, xD Picture Card [shared slots]
Ports
• Video
o RGB (monitor) output port
o S-Video output port
• Audio
o Microphone input port
o Headphone output port
• Data
o i.LINK(tm) IEEE-1394
o Universal Serial Bus (USB v2.0) – 3 ports
o RJ-45 LAN port
o RJ-11 modem port
Physical Description for this Product Series
• Dimensions (WxDxH Front/H Rear): 15.5” (394.0mm) x 11.0”
(280.3mm) x 1.17” (29.8mm)[F]/1.46” (37.0mm)[R] without feet
• Weight: Starting at 7.3 lbs (3.3 kg) depending upon configuration 12
