Toshiba P100-ST9012 - Manual

© Copyright 2005 – 2006 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite P100-ST9012 BTS Rev. 1.05 2006-08-28 SK T20060428 CB1.70 Page 1 of 5
Satellite P100-ST9012 Detailed Product Specification
1
Model Name Description Part Number UPC
P100-ST9012 Genuine Windows® XP Professional, Intel® Core™ Duo Processor T2400, 1024MB
DDR2 533MHz SDRAM, 80GB HDD (5400RPM). 17” WXGA+ TruBrite™, DVD
SuperMulti DL, Intel 802.11a/b/g, NVIDIA® GeForce® Go 7900GTX w/512MB GDDR3
VRAM, 5-in-1 Card reader, Fingerprint reader, Bluetooth v2.0+EDR, Dual-mode Pad,
1-Year Standard Limited Warranty. PSPA6U-02E012 032017624931
Section 1.01 Operating System
2
• Genuine Windows® XP Professional
• Windows Vista™ Premium Ready 3
• TOSHIBA Express Media Player
o Quick access for CD and DVD watching
Section 1.02 Processor and Chipset
4
Intel® Centrino® Duo Mobile Technology featuring:
• Processor
o Intel® Core™ Duo Processor T2400
ƒ 1.83GHz, 2MB L2, 667MHz FSB
• Chipset
o Mobile Intel® 945PM Express Chipset
• Integrated Wi-Fi® compliant wireless LAN
o Intel® PRO/Wireless 3945ABG (802.11a/b/g)
Section 1.03 Memory
5
• Configured with 1024MB PC4200 DDR2 533MHz SDRAM (both
memory slots are occupied)
• 1024MB (Min)/4096MB (Max), with 1024MB or 2048MB PC4200 or
PC5300 DDR2 memory modules.
Section 1.04 Hard Disk Drive 6
• 80GB (5400RPM) Serial-ATA (SATA) hard disk drive; 9.5mm
height; user removable
Section 1.05 Fixed Optical Disk Drive 7
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R
(24x), CD-RW (10x), DVD-ROM (8x), DVD-R (Single
Layer, (8x)), DVD-R (Double Layer, (2x)), DVD-RW (4x),
DVD+R (Single Layer, (8x)), DVD+R (Double Layer,
(2.4x)), DVD+RW (4x), DVD-RAM (5x)
Section 1.06 Display
8
• 17.0” diagonal widescreen TruBrite™ TFT active-matrix LCD
display at 1440x900 native resolution (WXGA+)
Section 1.07 Graphics
9
• PCI-Express™ x16 graphics subsystem, featuring:
o NVIDIA® GeForce® Go 7900GTX with 512MB GDDR3
SDRAM discrete graphics memory
Section 1.08 Sound
• Built-in harman/kardon® stereo speakers
• Sound Volume Control Dial
Section 1.09 Input Devices
• Keyboard
o 103 key US keyboard with 10-key
o Hot Key Functions (Fn)
o Windows Key Function
o Application Key Function
• Dual Mode Pad pointing device
• TouchPad™ Enable/Disable (FN+F9 or by help of software)
• Control Buttons:
o Internet button to launch default browser
o Express Media Player CD/DVD launch button
o CD/DVD control buttons (Skip to Previous/Next Track,
Play, Stop)
• Remote Control
o Express Media Player Remote Control
Section 1.10 Communications
• Toshiba V.92 software modem 10
• Intel® PRO/1000 PL Network Connection - 10/100/1000 Base-TX
Ethernet
• Intel® PRO/Wireless Network Connection 3945ABG
(802.11a/b/g) 11
• Bluetooth® version 2.0 plus Enhanced Data Rate (EDR) with
Toshiba Bluetooth driver software
• Consumer Infrared for remote control
Section 1.11 Expandability
• 2 main memory slots. Both slots may be occupied.
• One PCMCIA – Type II/Type I Card Slot
• ExpressCard™ slot supporting ExpressCard/34 and
ExpressCard/54
• 5-in-1 Bridge Media Adapter
o Secure Digital, Memory Stick™, Memory Stick PRO™,
Multi Media Card, xD Picture Card [shared slots]
Section 1.12 Ports
• Video
o RGB (monitor) output port
o S-Video output port
o DVI-D output port
• Audio
o S/P DIF output port (shared with headphone port)
o Microphone input port
o Headphone output port
• Data
o i.LINK™ IEEE-1394
o USB v2.0 – 4 ports
o RJ-45 LAN port
o RJ-11 modem port
Section 1.13 Physical Description for this Product Series
• Dimensions (WxDxH Front/H Rear): 15.5” (394.0mm) x 10.8”
(275.0mm) x 1.41” (35.9mm)[F]/1.65” (41.9mm)[R] without feet
• Weight: Starting at 7.1 lbs (3.2 kg) depending upon configuration 12
• Chassis Description
o Case material: Polycarbonate ABS
o LCD Cover Color: Mist Gray
• Physical Security
o Slot for cable lock;
o Items protected by a screw: Memory, Main HDD, WiFi
Card
o Fingerprint reader
• Software Security
o Passwords: User power-on password, supervisor
password
o Hotkey locks: Screen Blank
