User Manual – Interactive Digital Signage
SW601176 Rev A - Page 38 of 45
46” Interactive Digital Signage TouchMonitor
Available Touch Technologies APR
Display Active Area 1018.08 mm x 572.67 mm
LCD Panel type 46” TFT Active Matrix
Pixel Pitch 0.52025 mm x 0.53025 mm
LCD Panel native resolution 1920 x 1080
Contrast Ratio 3500 typical
Brightness
LCD Panel: 450 cd/m2 typical
With APR Touchscreen: 405 cd/m2 typical
Response Time 16 ms typical (Rise + Fall time)
Number of Displayable Colors 16.7 million
Viewing Angle 89º typical from left, right, top, and bottom sides
Video
Analog VGA connector: DE-15 Female
HDMI connector: HDMI Type A receptacle
H-Sync range: 31.5 – 80 KHz
V-Sync range: 48 – 62 Hz typ
Analog VGA levels: 0.7V
pp
into 75Ω terminations
Analog VGA Sync types: Separate, Composite, Sync-on-Green
Analog VGA Sync polarities: Positive or Negative
HDMI version supported: 1.3
Preset Video Modes:
640x480 60Hz
720x480 60Hz
800x600 56, 60Hz
1024x768 60Hz
1280x720 50, 60Hz
1280x960 60Hz
1280x1024 60Hz
1366x768 60Hz
1440x900 60Hz
1680x1050 60Hz
1920x1080 50, 60Hz
Plug And Play EDID 1.3 file provided over DDC2B interface
Audio
Input Connector: 3.5mm TRS jack
Input Signal Range: 1Vrms (0dBV) maximum
Internal Speakers: a pair of stereo 10W speakers
Headphone Output Connector: 3.5mm TRS jack
Headphone Output: capable of delivering 90mW per channel continuous
RMS power into a 32-ohm load (for a 1KHz signal at 0.2% THD)
