User Manual – Interactive Digital Signage
SW601176 Rev A - Page 26 of 45
OSD
Language
Selects which language the OSD information is displayed in. The available
languages are: English, French, Italian, German, Spanish, Simplified Chinese,
Traditional Chinese, and Japanese.
Default: English.
Mounting
Selects the touchmonitor mounting orientation between Landscape and Portrait to
match your physical orientation. This adjusts the rotation of the OSD text and which
bezel logo to light.
Default: Landscape
OSD
H-Position
Moves the OSD location left and right on the display.
Default: 50 (centered)
OSD
V-position Moves the OSD location up and down on the display.
Default: 50 (centered)
Volume
Adjusts the volume of the internal speakers and headphone output.
Mute
Toggles the audio output between Muted and Not Muted.
Default: Not Muted
Recall
Defaults
Selecting “Recall Defaults” restores all factory default settings for OSD-adjustable
parameters (except OSD Language and OSD Position) and for Preset Video Mode
timings.
Video Source
The monitor continually scans for active video from VGA, HDMI, and the Computer
Module. This adjustment selects which of those input ports should be given priority
to be displayed.
If there is no Computer Module plugged in, the options are: VGA Priority, HDMI
Priority
Default: HDMI Priority
When a Computer Module is plugged in, Computer Module HDMI is the only
displayable video source, and this adjustment is not available.
Audio Source
Selects which audio source is heard over the monitor’s speakers or headphone
output.
If there is no Computer Module plugged in, and the video source is HDMI, the options
are: Line In and HDMI.
Default: Line In.
If there is no Computer Module plugged in, and the video source is VGA, the only
option is Line In.
If a Computer Module is plugged in (and therefore the input video is Computer Module
HDMI), the options are: Elo Computer Module HDMI, Elo Computer Module Line In,
and Line In.
Default: Elo Computer Module HDMI.
All TouchMonitor adjustments made through the OSD are automatically memorized as soon as
they are entered. This feature saves you from having to reset your choices every time the
touchmonitor is unplugged or powered off and on. If there is a power failure, the touchmonitor
settings will not default to the factory specifications.
