Data Sheet: Supereta
TM
iQM Series –Single Output Quarter Brick
©2004-2006 TDK Innoveta Inc.
iQM 12V/17A Datasheet 8/4/2006
℡
(877) 498-0099
2/15
Ordering information:
Product
Identifier
Package
Size
Platform
Input
Voltage
Output
Current/
Power
Output
Units
Main
Output
Voltage
# of
Outputs
Safety
Class
Feature Set
i Q
M
48
017
A
120
V
-
0
00
TDK Innoveta
Quarter-
brick
Supereta
36-75V
017 – 17A
Amps
120 – 12V
Single
00 – Standard
Option Table:
Product Offering:
Code
Input Voltage
Output Voltage
Output
Current
Maximum
Output Power
Efficiency
iQM48017A120V 36-75V
12V
17A 204W 90.5%
Feature Set
On/Off Logic
OVP
Pin Length
00
Positive
Latch
0.145”
01 Negative
Latch
0.145”
02 Positive
Latch
0.110”
03 Negative
Latch
0.110”
04 Positive
Latch
0.200”
05 Negative
Latch
0.200”
06 Positive
Non-Latch
0.145”
07 Negative
Non-Latch
0.145”
08 Positive
Latch
0.180”
09 Negative
Latch
0.180”
