Tunturi R 710 User Manual
Page 26
26
1
103 2020
Frame (incl. 145)
1
2
423 2026
Decal set
1
3
203 2001
Mast tube
1
4
533 2025
Nylon bushing
2
5
533 2024
Sleeve
2
6
343 2009
Axle
1
7
403 2020
Extension cable
1
8
403 2022
Connecting cable
1
9
403 2021
Reseiver
1
10 173 2020
Cover for reseiver
1
11
M3x8 DIN 965
Screw
2
12 M4x10 DIN 965
Screw
2
13 M4 DIN 127
Washer
2
14 M4x10 DIN 7985 Screw
2
15 523 2019
Sleeve
6
16 653 2009
Eye Bolt
2
17 653 2010
Cap for eye bolt
2
18 M5 DIN 125
Washer
2
38 AR01-038
Rope plate
1
40 AB02-066
Axle assy
1
41 AR01-041
Bearing housing, L(incl.128) 1
42 AR02-042
Fan blade
6
45 AR01-045
Drive pulley assy
1
47 AR01-047
Spacer
1
48 AR01-048
Bearing , R (incl.127, 128) 1
50 AR01-051
Tension spring assy
2
53 AR01-053
Rope housing
1
55 443 2010
Rope, compl.
1
56 AB01-048
Fan wheel
1
57 AB01-074
Cage, pair
1
58 AB01-075
Trim strip
1
59 AR02-059
Axle cover, pair
1
62 AR02-062
Side cover, pair
1
63 433 2015
Electr. mounting plate
1
64* RB01-032
Seat stop
2
67 AR01-067
Front stand tube
1
68 AB01-077A
Sleeve
2
69 AB01-078
End cap
4
70 AR01-070
Foot
2
71 AB02-072G
Transport wheel
4
72 AR01-072
Axle
4
73 AR01-073
Pulley
1
74 343 2008
Axle
1
75 203 2002
Handlebar (incl. 76)
1
76 AR02-076
Handlebar grip
2
80 103 2022
Rear stand support
1
81 AR01-081
End cap
1
82 AR01-082
Seat bracket
1
83 AR01-083
Roller
3
85 AR01-085
Washer
6
86 AR01-086
Axle
3
87* AR01-087
Nut plate
1
88 AR01-088
Pulley cover
1
89* AR02-089
Axle
1
91 103 2021
Rail (incl. 7-12, 81, 112)
1
95 AR02-095
Locking pin
1
98 AR01-098
Pedal mount assy
1
99 AR01-099
Rubber sleeve
2
101* PO R701
Pedal axle
1
102 AR01-102
Foot pedal plate, pair
1
103 AR01-103
Foot pedal assy, pair
1
105 533 2023
Nylon sleeve
6
111 233 2015
Electronics module
1
112 403 2019
Sensor + cable
1
113 AR02-113
Seat
1
115 AR01-115
Drive belt
1
127 19 DIN 471
C-Clip
1
128 17 DIN 471
C-Clip
2
129 35 DIN 472
C-Clip internal
3
130 3/16”x3/8” UNC Screw
6
131 3/16”x5/8” UNC Screw
7
136* M10 DIN 125
Washer
4
137 M4x12 DIN 7500C Screw
8
138 M3x10 DIN 7985 Screw
2
139 1/4”-20x1/2”UNC Screw
4
140* AR01-140
Screw
2
141 M8 DIN 985
Nut
3
142 1/4”-20 UNC
Nut
4
143 1/4”-24 UNC
Nut
2
145 M4 DIN 955
Nut clip
8
146 M4x12 DIN 7985 Screw
8
147* 3/8”-16 UNC
Nut nylon
3
148* M5x15 DIN 7985 Screw
2
149* M8 DIN 127
Washer (* 8 pcs)
10
150* M8x19 ISO 7380 Screw
8
151 M6x15 DIN 7985 Screw
4
152 M6 DIN 125
Washer
4
162 M6 DIN 440
Washer
2
163 1/4”-24 UNC
Nut
1
164 M5x18 DIN 7981 Screw
8
172 M5x25 DIN 7500C Screw
2
-
R701A
Hardware kit
1
-
583 2010
Owner’s manual
1
