24
SYSTEM V NET 15BP V NET 15HL V NET 18DR
System Type Subwoofer - Band Pass Full Range — Horn Loaded Full Range — Direct Radiating
Frequency Response (1) +/- 3dB 35Hz - 150Hz 48Hz - 250Hz 27Hz - 200Hz
Maximum SPL (2) Average 127dB 130dB 130dB
Peak 133dB 136dB 136dB
Driver Complement 1 x 380mm (15 ) 1 x 380mm (15 ) 1 x 458mm (18 )
Bass Unit
Crossover (DSP Generated)
Variable LPF Variable LPF Variable LPF
Distortion
0.1 Full Power
2nd Harmonic 3rd Harmonic 2nd Harmonic 3rd Harmonic 2nd Harmonic 3rd Harmonic
50 Hz 0.22% 0.71% 0.89% 0.15% 0.25% 0.19%
100 Hz 0.56% 0.31% 0.14% 0.10% 0.20% 0.15%
0.01 Full Power 2nd Harmonic 3rd Harmonic 2nd Harmonic 3rd Harmonic 2nd Harmonic 3rd Harmonic
50 Hz 0.21% 0.31% 0.11% 0.05% 0.19% 0.10%
100 Hz 0.25% 0.18% 0.79% 0.09% 0.14% 0.11%
CONSTRUCTION
Enclosure 100 litre Bandpass Horn Loaded 202 litre Direct Radiating
15mm ( 5 / 8 ) 18mm ( 11 / 16 ) 18mm ( 11 / 16 )
multiple-ply birch plywood multiple-ply birch plywood multiple-ply birch plywood
Finish Textured Black or White paint (Custom colours on request).
Connectors 1 x female XLR (input), 1 x RJ45 (network in), 1 male XLR (link), 1 x RJ45 (network link),
1 x Neutrik Powercon
Fittings 2 x recessed carrying handle 2 x recessed carrying handle 4 x recessed carrying handle
Blanking plate for optional VTH pole mount
8 x M10 inserts for flying
4 x rubber feet
Dimensions 665 x 440 x 440mm 578 x 555 x 650mm 790 x 685 x 900mm
(26 3 / 16 x 17 5 / 16 x 17 5 / 16 ) (22 x 21 7 / 8 x 25 9 / 16 ) (27 15 / 16 x 25 9 / 16 X 21 7 / 8 )
Weight 31kg (70lbs) 44kg (98lbs 10oz) 55kg (121lbs)
NOTES: (1) Average over stated bandwidth. Measured at 1 metre on axis.
(2) Unweighted pink noise input, measured at 1 metre in an anechoic chamber
A full range of measurements, performance data, and Ease“ Data can be downloaded from www.tannoy.com
Tannoy operates a policy of continuous research and development. The introduction of new materials or manufacturing methods will always equal or exceed the published specifications, which Tannoy reserves
the right to alter without prior
ELECTRONICS (Common to all models)
Efficiency >85% typically
Damping Factor 120 ref 8
Distortion <0.05% @ 1kHz -3dB output
(22kHz bandwidth)
Input Impedance 5.6k unbalanced, 11.2k balanced
Output Power (Programme) VNET 12 VNET 12HP VNET 15 VNET 300 VNET15BP VNET15HL VNET18DR
400W LF 700W LF 800W LF 500W LF 600W 800W 1200W
400W HF (limited) 700W H ( limited) 800W HF (limited) 500W HF (limited)
Input Sensitivity 1.4V (+5.5dBu)
System Type Dual channel Class D
DSP system (Common to all models)
Comms Facilities Firmware updatable and selected parameters editable
Communications Serial - RS485 Proprietary message format
Dynamic Range 112dB(A) typical
DSP 3rd generation SHARC
Sampling Frequency 96kHz 24 bit A/D-D/A word length
Format 1 IN - 2 OUT
PSU specifications (Common to all models)
Input Connector Locking Neutrik Powercon
Voltage Selection Automatic (115 / 230V, 45 - 65Hz)
Switching Frequency 192kHz Syncronised to DSP
13.0: TECHNICAL SPECIFICATIONS
