background image

TASCAM CD-RW5000

23

6 - Specifications

6.1 Audio specifications

6.2 I/O specifications

Recording time

74 minutes (with 74-minute disc)

CD type

Playback of CD-DA (Red Book),
CD-R and CD-RW
Recording on CD-R and
CD-RW

a

a. Brands of disc that are recommended for used

with the CD-RW5000 are the Taiyo Yuden and
Ricoh brands.

Input sampling frequency

32 kHz — 48 kHz

b

b. The CD-RW5000 incorporates an automatic

sampling frequency convertor to convert input
to 44.1 kHz. However, the following should be
noted. The sampling frequency convertor is
activated when the sampling frequency falls
outside 44.1 kHz (to a tolerance of

±

100ppm).

If the input signal suffers from jitter, and
“drifts” around the nominal 44.1 kHz fre-
quency, the sampling frequency convertor will
keep engaging and disengaging, producing
audible noise in the recording.

Recording sampling
frequency

44.1 kHz

Recording resolution

16-bit linear

Frequency response

20 Hz to 20,000 Hz (

±

0.5 dB

playback,

±

1 dB recording)

S/N ratio

>98 dB (playback), >90 dB
(recording)

Dynamic range

>95 dB (playback), >90 dB
(recording)

Total harmonic distortion
(1 kHz @ FS – 1.1 dB at
recording)

<0.008% (playback), < 0.012%
recording)

Channel separation

>90 dB (playback), >86 dB
(recording) (1kHz @ FS)

Wow and flutter

Unmeasurable (<0.001%)

Analog inputs (balanced
XLR-3-31 type)

Nominal input level +4dBu
(FS=–16 dB)
Maximum input level +20 dBu
Input impedance 10 k

Analog inputs (unbal-
anced RCA)

Nominal input level –10dBV
(FS=–16 dB)
Maximum input level +6 dBV
(2Vrms)
Input impedance 10 k

Analog outputs (balanced
XLR-3-32 type)

Nominal output level +4dBu
(FS=–16 dBu)
Maximum output level +20 dBu
All level measurements made
with trimmer set to maximum
value
Output impedance 75

Trimmers provide up to 12 dB of
attenuation

Analog outputs (unbal-
anced RCA)

Nominal output level –10 dBV
Maximum output level +6 dBV
(2 Vrms)
Output impedance 200

Headphone 1/4-inch
stereo jack

(2 x 32 mW into 32

Ω)

Digital output (optical
TOSLINK)

IEC60958 format (Type II)

a

a. IEC-60958 Type I (AES3-1992) is a standard

for broadcasting studios (professional). It can-
not be used for connecting consumer products.
IEC-60958 Type II (SPDIF) is a standard for
consumer products.

Digital output (unbalanced
RCA)

IEC60958 format (Type II)

Digital input (balanced
XLR-3-31 type)

AES3-1992 (Type I)

a

or

IEC60958 format (Type II)

Digital input (unbalanced
RCA)

AES3-1992 (Type I) or
IEC60958 format (Type II)

Digital input (optical
TOSLINK)

AES3-1992 (Type I) or
IEC60958 format (Type II)

Parallel I/O port

15-pin ’D’-sub connector

REMOTE CONTROL
3.5 mm mini-jack

For use with supplied
RC-RW5000 remote control unit
only
